1883 mm (74 in), Base Edge

Get in touch

Cat® Utility Buckets for Cat Skid Steer Loaders and Compact Track Loaders are designed to grade, level and stockpile light materials, such as mulch, dry topsoil, livestock feed and waste.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Width

74.1 in 1883 mm
{"Name":"Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"74.1","MetricUnit":"mm","MetricValue":"1883","Type":"measurement","SpecificationGroup":null,"SortOrder":"1"}
Capacity

0.68 yd³ 0.52 m³
{"Name":"Capacity","SpecificationId":null,"TextValue":null,"EnglishUnit":"yd³","EnglishValue":"0.68","MetricUnit":"m³","MetricValue":"0.52","Type":"measurement","SpecificationGroup":null,"SortOrder":"2"}
Weight

526.9 lb 239 kg
{"Name":"Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"526.9","MetricUnit":"kg","MetricValue":"239","Type":"measurement","SpecificationGroup":null,"SortOrder":"3"}
Height

21 in 533 mm
{"Name":"Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"21","MetricUnit":"mm","MetricValue":"533","Type":"measurement","SpecificationGroup":null,"SortOrder":"4"}
Length

31.1 in 789 mm
{"Name":"Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"31.1","MetricUnit":"mm","MetricValue":"789","Type":"measurement","SpecificationGroup":null,"SortOrder":"5"}
Base Edge Thickness

0.7 in 19 mm
{"Name":"Base Edge Thickness","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"0.7","MetricUnit":"mm","MetricValue":"19","Type":"measurement","SpecificationGroup":null,"SortOrder":"6"}
Interface Type

Skid Steer Coupler
{"Name":"Interface Type","SpecificationId":null,"TextValue":"Skid Steer Coupler","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"8"}

Benefits

Diverse Applications

Designed for handling lower density materials such as mulch, dry topsoil, livestock feed and waste in agricultural and landscaping settings.

Material Retention

Longer floor length and taller back height provide excellent material retention.

Dual Angled Side Plates

Taller, dual angled side plates aid in the retention of loose, more flowing materials such as feed or fertilizer.

Hardened Edges

Hardened steel base and side cutting edges provide excellent penetration, durability and wear life.
