2.8 m (9 ft), Skid Steer Coupler

Get in touch

Cat® Snow Wings are designed with versatility in mind. With independently controlled wings and angling capability, the attachment can be configured to suit the needs of any job and continue to adapt to ever changing needs by being able to hydraulically configure for plowing, pushing, and backdraging to enable cleaning and maintaining roadways, sidewalks and other passages for safe passage in winter conditions.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Working Width (Wings Closed)

108.5 in 2756 mm
{"Name":"Working Width (Wings Closed)","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"108.5","MetricUnit":"mm","MetricValue":"2756","Type":"measurement","SpecificationGroup":null,"SortOrder":"1"}
Overall Width (Wings Closed)

116.2 in 2951 mm
{"Name":"Overall Width (Wings Closed)","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"116.2","MetricUnit":"mm","MetricValue":"2951","Type":"measurement","SpecificationGroup":null,"SortOrder":"2"}
Overall Width (Wings Open)

173.7 in 4411 mm
{"Name":"Overall Width (Wings Open)","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"173.7","MetricUnit":"mm","MetricValue":"4411","Type":"measurement","SpecificationGroup":null,"SortOrder":"3"}
Working Width (Wings Open)

173.7 in 4411 mm
{"Name":"Working Width (Wings Open)","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"173.7","MetricUnit":"mm","MetricValue":"4411","Type":"measurement","SpecificationGroup":null,"SortOrder":"4"}
Weight

1951.1 lb 885 kg
{"Name":"Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"1951.1","MetricUnit":"kg","MetricValue":"885","Type":"measurement","SpecificationGroup":null,"SortOrder":"5"}
Length

67.1 in 1705 mm
{"Name":"Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"67.1","MetricUnit":"mm","MetricValue":"1705","Type":"measurement","SpecificationGroup":null,"SortOrder":"6"}
Overall Height

36 in 915 mm
{"Name":"Overall Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"36","MetricUnit":"mm","MetricValue":"915","Type":"measurement","SpecificationGroup":null,"SortOrder":"7"}
Hydraulic Angling - Left/Right of Center

±35 Degrees
{"Name":"Hydraulic Angling - Left/Right of Center","SpecificationId":null,"TextValue":"±35 Degrees","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"8"}
Float

±5 Degrees
{"Name":"Float","SpecificationId":null,"TextValue":"±5 Degrees","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"9"}
Wing Rotation

180 Degrees
{"Name":"Wing Rotation","SpecificationId":null,"TextValue":"180 Degrees","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"10"}
Optimal Hydraulic Flow

76-87 L/min (20-23 gpm)
{"Name":"Optimal Hydraulic Flow","SpecificationId":null,"TextValue":"76-87 L/min (20-23 gpm)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"11"}
Optimal Hydraulic Pressure

200-230 bar (2800-3300 psi)
{"Name":"Optimal Hydraulic Pressure","SpecificationId":null,"TextValue":"200-230 bar (2800-3300 psi)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"12"}
Interface Type

Skid Steer Coupler
{"Name":"Interface Type","SpecificationId":null,"TextValue":"Skid Steer Coupler","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"13"}
Trip Edge Type

Steel
{"Name":"Trip Edge Type","SpecificationId":null,"TextValue":"Steel","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"14"}
Trip Edge Height

5.1 in 130 mm
{"Name":"Trip Edge Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"5.1","MetricUnit":"mm","MetricValue":"130","Type":"measurement","SpecificationGroup":null,"SortOrder":"15"}
Trip Edge Quantity

1
{"Name":"Trip Edge Quantity","SpecificationId":null,"TextValue":"1","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"16"}
Required Hydraulics

Standard Flow w/14 pin Electrical
{"Name":"Required Hydraulics","SpecificationId":null,"TextValue":"Standard Flow w/14 pin Electrical","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"17"}

Benefits

Cat® Customer Value Agreements simplify ownership with planned maintenance, genuine parts, dealer expertise, and smart monitoring to reduce costs and extend machine life. Flexible plans and options for customer‑managed (Convenience plan), dealer‑managed (Performance plan), or protection‑focused (Confidence) coverage.. With Toromont Fast Track, exclusive to Cat® CVAs, you get next‑day parts, two‑day repairs, and Cat® Credits if delays occur—keeping downtime off your schedule.

Curved Moldboard

Curved moldboard design rolls and folds the snow while windrowing, minimizing snow clinging to its surface and spilling over the top.

Adjustable Rear Skid Shoes

Adjustable skid shoes reduce the chances of gouging plowed surface and allow for improved operator control and maintains a constant cutting edge depth.

Lateral Float

Lateral float allows the plow the ability to pivot up to five degrees about the plow frame allowing the blade to follow surface contours and plow more efficiently.

Adjustable Trip Edges

Adjustable trip edges are incorporated into the base of each wing. Sectioned off moldboard springs back upon contact with unseen obstacles minimizing risk of damage to the wing and machine.

Bolt-On Serrated Step

Bolt-On serrated step provides safe and ergonomic access to machine cab that is replaceable if damaged.

Rotary Actuators

Allows 180 degrees of rotation for each wing for maximum versatility. Both wings are independently controlled. The use of actuators rather than cylinders also keeps the components better protected from damage.

Wing Stops

Stops on the attachment keep the wings from contacting the tires or tracks of the machine regardless of plow angle to prevent damage.

Up to 35 Degree Angle

Plow can angle left or right 35 degrees allowing the operator more control over direction of the snow.

Reversible Cutting Edge

Cutting edge is easy to replace, and can be reversed when dull to get another life.

Floating End Plate Edge

Follow surface contour for more consistent snow clearing.

Adjustable Crossover Relief Valve

Crossover relief allows plow to angle if it impacts a solid object. This helps prevent damage to the attachment in extreme conditions.

Tool Mounted OMM Holder

Tool mounted and sealed from the elements, this holder includes all of the operation manuals and maintenance guides required for proper operation of the work tool.
