SR421

Get in touch

Cat® Snow Blowers are designed for removing snow from streets, parking lots, driveways and sidewalks, making them ideal for various winter cleanup and maintenance applications.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Intake Width

76.5 in 1942 mm
{"Name":"Intake Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"76.5","MetricUnit":"mm","MetricValue":"1942","Type":"measurement","SpecificationGroup":null,"SortOrder":"1"}
Overall Width

85.9 in 2181 mm
{"Name":"Overall Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"85.9","MetricUnit":"mm","MetricValue":"2181","Type":"measurement","SpecificationGroup":null,"SortOrder":"2"}
Weight

1016.3 lb 535 kg
{"Name":"Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"1016.3","MetricUnit":"kg","MetricValue":"535","Type":"measurement","SpecificationGroup":null,"SortOrder":"3"}
Overall Height

72.6 in 1843 mm
{"Name":"Overall Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"72.6","MetricUnit":"mm","MetricValue":"1843","Type":"measurement","SpecificationGroup":null,"SortOrder":"4"}
Overall Length

37.4 in 951 mm
{"Name":"Overall Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"37.4","MetricUnit":"mm","MetricValue":"951","Type":"measurement","SpecificationGroup":null,"SortOrder":"5"}
Required Hydraulics

XHP / XE
{"Name":"Required Hydraulics","SpecificationId":null,"TextValue":"XHP / XE","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"6"}
Optimal Hydraulic Flow

125-150 L/min (33-40 gpm)
{"Name":"Optimal Hydraulic Flow","SpecificationId":null,"TextValue":"125-150 L/min (33-40 gpm)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"7"}
Optimal Hydraulic Pressure

200-280 bar (2800-4100 psi)
{"Name":"Optimal Hydraulic Pressure","SpecificationId":null,"TextValue":"200-280 bar (2800-4100 psi)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"8"}
Cutting Height

34.1 in 867 mm
{"Name":"Cutting Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"34.1","MetricUnit":"mm","MetricValue":"867","Type":"measurement","SpecificationGroup":null,"SortOrder":"9"}
Maximum Throw

40 ft 12.2 m
{"Name":"Maximum Throw","SpecificationId":null,"TextValue":null,"EnglishUnit":"ft","EnglishValue":"40","MetricUnit":"m","MetricValue":"12.2","Type":"measurement","SpecificationGroup":null,"SortOrder":"10"}
Auger Diameter

18 in 457 mm
{"Name":"Auger Diameter","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"18","MetricUnit":"mm","MetricValue":"457","Type":"measurement","SpecificationGroup":null,"SortOrder":"11"}
Impeller Fan Diameter

25 in 635 mm
{"Name":"Impeller Fan Diameter","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"25","MetricUnit":"mm","MetricValue":"635","Type":"measurement","SpecificationGroup":null,"SortOrder":"12"}
Impeller Fan Width

8.7 in 222 mm
{"Name":"Impeller Fan Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"8.7","MetricUnit":"mm","MetricValue":"222","Type":"measurement","SpecificationGroup":null,"SortOrder":"13"}
Chute Rotation

270 degrees
{"Name":"Chute Rotation","SpecificationId":null,"TextValue":"270 degrees","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"14"}

Benefits

Application

Designed for removing snow from streets, parking lots, driveways and sidewalks.

Two Stage Design

Two-stage design uses auger and impeller to move a greater capacity of snow quickly and efficiently. Also, the auger and impeller are reversible which allows the operator to expel obstructions without exiting the machine.

Fan Style Impeller

Provides smooth operation and continuous flow of material in a variety of snow conditions.

Hydraulic Controls

Machine joysticks control chute and deflector. No additional wires or hardware to connect. Complete control with plug-n-play simplicity.

Chute Rotation and Deflector

270 degrees of rotation permits snow discharge to front or sides of machine preventing snow blow back on operator. Hydraulically controlled deflector makes it easy to control how far snow is thrown.

Offset Chute

Improves visibility and allows full range of motion on Compact Wheel Loader machines.

Adjustable Skid Shoes

Adjust height of cutting edge to suit the job needs.

Reversible Bolt-On Cutting Edge

Bolt-on reversible cutting edge adds extra life to the cutting edge and make replacement simple.

Rugged Access Step and Grab Handle

Wide steps with grating and large profile serrations provide better traction. Chute mounted grab handle allows stability when entering and exiting machine.

OMM Container

Tool mounted and sealed from the elements, this holder includes all the operation manuals and maintenance guides required for proper operation of the tool.
