226D3

Get in touch

Built for tough work, the Cat® Skid Steer Loaders incorporate big iron features. These machines deliver reliability, durability, and efficient operation, even in the toughest working conditions.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Air Conditioning System (if equipped)

Air Conditioning

The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.81 kg of refrigerant which has a CO2 equivalent of 1.158 metric tonnes.
{"Name":"Air Conditioning","SpecificationId":null,"TextValue":"The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.81 kg of refrigerant which has a CO2 equivalent of 1.158 metric tonnes.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Air Conditioning System (if equipped)","SortOrder":"99"}

Cab

ROPS

ISO 3471:2008
{"Name":"ROPS","SpecificationId":null,"TextValue":"ISO 3471:2008","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Cab","SortOrder":"45"}
FOPS

ISO 3449:2005 Level I
{"Name":"FOPS","SpecificationId":null,"TextValue":"ISO 3449:2005 Level I","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Cab","SortOrder":"46"}

Dimensions

Wheel Base

41.5 in 1054 mm
{"Name":"Wheel Base","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"41.5","MetricUnit":"mm","MetricValue":"1054","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"19"}
Length - With Bucket on Ground

127.3 in 3234 mm
{"Name":"Length - With Bucket on Ground","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"127.3","MetricUnit":"mm","MetricValue":"3234","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"20"}
Length - Without Bucket

99.4 in 2524 mm
{"Name":"Length - Without Bucket","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"99.4","MetricUnit":"mm","MetricValue":"2524","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"21"}
Height - Top of Cab

79.8 in 2028 mm
{"Name":"Height - Top of Cab","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"79.8","MetricUnit":"mm","MetricValue":"2028","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"22"}
Vehicle Width over Tires

58.9 in 1497 mm
{"Name":"Vehicle Width over Tires","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"58.9","MetricUnit":"mm","MetricValue":"1497","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"23"}
Maximum Overall Height

143.8 in 3652 mm
{"Name":"Maximum Overall Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"143.8","MetricUnit":"mm","MetricValue":"3652","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"24"}
Bucket Pin Height - Maximum Lift

110.9 in 2818 mm
{"Name":"Bucket Pin Height - Maximum Lift","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"110.9","MetricUnit":"mm","MetricValue":"2818","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"25"}
Bucket Pin Height - Carry Position

8.5 in 215 mm
{"Name":"Bucket Pin Height - Carry Position","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"8.5","MetricUnit":"mm","MetricValue":"215","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"26"}
Reach - Maximum Lift/Dump

21 in 533 mm
{"Name":"Reach - Maximum Lift/Dump","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"21","MetricUnit":"mm","MetricValue":"533","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"27"}
Clearance at Maximum Lift and Dump

81.8 in 2077 mm
{"Name":"Clearance at Maximum Lift and Dump","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"81.8","MetricUnit":"mm","MetricValue":"2077","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"28"}
Ground Clearance

6.9 in 175 mm
{"Name":"Ground Clearance","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"6.9","MetricUnit":"mm","MetricValue":"175","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"29"}
Departure Angle

27.9°
{"Name":"Departure Angle","SpecificationId":null,"TextValue":"27.9°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"30"}
Maximum Dump Angle

46.7°
{"Name":"Maximum Dump Angle","SpecificationId":null,"TextValue":"46.7°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"32"}
Rack Back Angle - Maximum Height

88.9°
{"Name":"Rack Back Angle - Maximum Height","SpecificationId":null,"TextValue":"88.9°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"37"}
Bumper Overhang - Behind Rear Axle

35.2 in 8944 mm
{"Name":"Bumper Overhang - Behind Rear Axle","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"35.2","MetricUnit":"mm","MetricValue":"8944","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Turning Radius from Center - Bucket

77.8 in 1977 mm
{"Name":"Turning Radius from Center - Bucket","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"77.8","MetricUnit":"mm","MetricValue":"1977","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Maximum Reach - With Arms Parallel to Ground

50.7 in 1288 mm
{"Name":"Maximum Reach - With Arms Parallel to Ground","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"50.7","MetricUnit":"mm","MetricValue":"1288","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Turning Radius from Center - Machine Rear

59.6 in 1513 mm
{"Name":"Turning Radius from Center - Machine Rear","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"59.6","MetricUnit":"mm","MetricValue":"1513","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Turning Radius from Center - Coupler

43.5 in 1104 mm
{"Name":"Turning Radius from Center - Coupler","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"43.5","MetricUnit":"mm","MetricValue":"1104","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Note

* Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, single speed, 1576 mm (62 in) low profile bucket, Cat 10 × 16.5 tires, standard flow hydraulics, C1 cab (OROPS, mechanical seat), 850 CCA battery, manual quick coupler, no self level and no optional counterweights (unless otherwise noted).
{"Name":"Note","SpecificationId":null,"TextValue":"* Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, single speed, 1576 mm (62 in) low profile bucket, Cat 10 × 16.5 tires, standard flow hydraulics, C1 cab (OROPS, mechanical seat), 850 CCA battery, manual quick coupler, no self level and no optional counterweights (unless otherwise noted).","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"99"}

Engine

Gross Power - SAE J1995:2014

67.1 hp 50.1 kW
{"Name":"Gross Power - SAE J1995:2014","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"67.1","MetricUnit":"kW","MetricValue":"50.1","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"1"}
Net Power - SAE 1349

65.8 hp 49.1 kW
{"Name":"Net Power - SAE 1349","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"65.8","MetricUnit":"kW","MetricValue":"49.1","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"10"}
Displacement

134.3 in³ 2.2 l
{"Name":"Displacement","SpecificationId":null,"TextValue":null,"EnglishUnit":"in³","EnglishValue":"134.3","MetricUnit":"l","MetricValue":"2.2","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"11"}
Stroke

3.9 in 100 mm
{"Name":"Stroke","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"3.9","MetricUnit":"mm","MetricValue":"100","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"12"}
Bore

3.3 in 84 mm
{"Name":"Bore","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"3.3","MetricUnit":"mm","MetricValue":"84","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"13"}
Engine Model

Cat C2.2 CRDI
{"Name":"Engine Model","SpecificationId":null,"TextValue":"Cat C2.2 CRDI","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}
Peak Torque - 1,500 rpm - SAE J1995

153 ft·lbf 208 N·m
{"Name":"Peak Torque - 1,500 rpm - SAE J1995","SpecificationId":null,"TextValue":null,"EnglishUnit":"ft·lbf","EnglishValue":"153","MetricUnit":"N·m","MetricValue":"208","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Net Power - ISO 9249

66.5 hp 49.6 kW
{"Name":"Net Power - ISO 9249","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"66.5","MetricUnit":"kW","MetricValue":"49.6","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}

Hydraulic System

Hydraulic Flow - Standard - Loader Hydraulic Pressure

3336 psi 23000 kPa
{"Name":"Hydraulic Flow - Standard - Loader Hydraulic Pressure","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"3336","MetricUnit":"kPa","MetricValue":"23000","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - High Flow - Maximum Loader Hydraulic Pressure

3336 psi 23000 kPa
{"Name":"Hydraulic Flow - High Flow - Maximum Loader Hydraulic Pressure","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"3336","MetricUnit":"kPa","MetricValue":"23000","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - Standard - Hydraulic Power (Calculated)

33.5 hp 26.5 kW
{"Name":"Hydraulic Flow - Standard - Hydraulic Power (Calculated)","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"33.5","MetricUnit":"kW","MetricValue":"26.5","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - High Flow - Hydraulic Power (Calculated)

50.9 hp 38 kW
{"Name":"Hydraulic Flow - High Flow - Hydraulic Power (Calculated)","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"50.9","MetricUnit":"kW","MetricValue":"38","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - Standard - Loader Hydraulic Flow

18 gpm 69 L/min
{"Name":"Hydraulic Flow - Standard - Loader Hydraulic Flow","SpecificationId":null,"TextValue":null,"EnglishUnit":"gpm","EnglishValue":"18","MetricUnit":"L/min","MetricValue":"69","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - High Flow - Maximum Loader Hydraulic Flow

26 gpm 99 L/min
{"Name":"Hydraulic Flow - High Flow - Maximum Loader Hydraulic Flow","SpecificationId":null,"TextValue":null,"EnglishUnit":"gpm","EnglishValue":"26","MetricUnit":"L/min","MetricValue":"99","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}

Noise Level

Outside Cab***

102 dB(A) 102 dB(A)
{"Name":"Outside Cab***","SpecificationId":null,"TextValue":null,"EnglishUnit":"dB(A)","EnglishValue":"102","MetricUnit":"dB(A)","MetricValue":"102","Type":"measurement","SpecificationGroup":"Noise Level","SortOrder":"99"}
Inside Cab**

83 dB(A) 83 dB(A)
{"Name":"Inside Cab**","SpecificationId":null,"TextValue":null,"EnglishUnit":"dB(A)","EnglishValue":"83","MetricUnit":"dB(A)","MetricValue":"83","Type":"measurement","SpecificationGroup":"Noise Level","SortOrder":"99"}
Note (3)

***The labeled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC.
{"Name":"Note (3)","SpecificationId":null,"TextValue":"***The labeled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Noise Level","SortOrder":"99"}
Note (1)

Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe.
{"Name":"Note (1)","SpecificationId":null,"TextValue":"Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Noise Level","SortOrder":"99"}
Note (2)

**The declared dynamic operator sound pressure levels per ISO 6396:2008. The measurements were conducted with the cab doors and windows closed and at 70% of the maximum engine cooling fan speed. The sound level may vary at different engine cooling fan speeds.
{"Name":"Note (2)","SpecificationId":null,"TextValue":"**The declared dynamic operator sound pressure levels per ISO 6396:2008. The measurements were conducted with the cab doors and windows closed and at 70% of the maximum engine cooling fan speed. The sound level may vary at different engine cooling fan speeds.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Noise Level","SortOrder":"99"}

Operating Specifications

Rated Operating Capacity

1550 lb 705 kg
{"Name":"Rated Operating Capacity","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"1550","MetricUnit":"kg","MetricValue":"705","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"2"}
Rated Operating Capacity with Optional Counterweight

1650 lb 750 kg
{"Name":"Rated Operating Capacity with Optional Counterweight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"1650","MetricUnit":"kg","MetricValue":"750","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"14"}
Tipping Load

3100 lb 1410 kg
{"Name":"Tipping Load","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"3100","MetricUnit":"kg","MetricValue":"1410","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"15"}
Breakout Force - Tilt Cylinder

3927 lb 1781 kg
{"Name":"Breakout Force - Tilt Cylinder","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"3927","MetricUnit":"kg","MetricValue":"1781","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"16"}
Note

* Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, single speed, 1576 mm (62 in) low profile bucket, Cat 10 × 16.5 tires, standard flow hydraulics, C1 cab (OROPS, mechanical seat), 850 CCA battery, manual quick coupler, no self level and no optional counterweights (unless otherwise noted).
{"Name":"Note","SpecificationId":null,"TextValue":"* Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, single speed, 1576 mm (62 in) low profile bucket, Cat 10 × 16.5 tires, standard flow hydraulics, C1 cab (OROPS, mechanical seat), 850 CCA battery, manual quick coupler, no self level and no optional counterweights (unless otherwise noted).","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Operating Specifications","SortOrder":"99"}

Power Train

Travel Speed - Forward or Reverse - One Speed

7.6 mile/h 12.3 km/h
{"Name":"Travel Speed - Forward or Reverse - One Speed","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"7.6","MetricUnit":"km/h","MetricValue":"12.3","Type":"measurement","SpecificationGroup":"Power Train","SortOrder":"99"}
Travel Speed - Forward or Reverse - Two Speed Option

11.1 mile/h 17.8 km/h
{"Name":"Travel Speed - Forward or Reverse - Two Speed Option","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"11.1","MetricUnit":"km/h","MetricValue":"17.8","Type":"measurement","SpecificationGroup":"Power Train","SortOrder":"99"}

Service Refill Capacities

Chain Box - Each Side

1.8 gal (US) 7 l
{"Name":"Chain Box - Each Side","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"1.8","MetricUnit":"l","MetricValue":"7","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"51"}
Cooling System

3.2 gal (US) 12 l
{"Name":"Cooling System","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"3.2","MetricUnit":"l","MetricValue":"12","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"52"}
Engine Crankcase

2.6 gal (US) 10 l
{"Name":"Engine Crankcase","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"2.6","MetricUnit":"l","MetricValue":"10","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"53"}
Fuel Tank

15.1 gal (US) 57 l
{"Name":"Fuel Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"15.1","MetricUnit":"l","MetricValue":"57","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"54"}
Hydraulic System

11.9 gal (US) 45 l
{"Name":"Hydraulic System","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"11.9","MetricUnit":"l","MetricValue":"45","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"55"}
Hydraulic Tank

9 gal (US) 34 l
{"Name":"Hydraulic Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"9","MetricUnit":"l","MetricValue":"34","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"56"}

Weights

Operating Weight

5849 lb 2653 kg
{"Name":"Operating Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"5849","MetricUnit":"kg","MetricValue":"2653","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"3"}
Note

* Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, single speed, 1576 mm (62 in) low profile bucket, Cat 10 × 16.5 tires, standard flow hydraulics, C1 cab (OROPS, mechanical seat), 850 CCA battery, manual quick coupler, no self level and no optional counterweights (unless otherwise noted).
{"Name":"Note","SpecificationId":null,"TextValue":"* Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, single speed, 1576 mm (62 in) low profile bucket, Cat 10 × 16.5 tires, standard flow hydraulics, C1 cab (OROPS, mechanical seat), 850 CCA battery, manual quick coupler, no self level and no optional counterweights (unless otherwise noted).","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Weights","SortOrder":"99"}

Benefits

Quiet and Comfortable

The industry leading sealed and pressurized cab option provides the operator with a cleaner and quieter operating environment with excellent work tool visibility. Continuing the industry leading trend, the D3 Series also includes as standard, seat mounted adjustable joystick controls for operator comfort.

Maximum Performance

High performance power train provides maximum performance and production capability through the Electronic Torque Management system, standard two speed travel and an electronic hand/foot throttle with decel pedal capability.

Making Your Job Easier

Cat® “Intelligent Leveling” system provides industry leading technology, integration, and available features such as dual direction self level, work tool return to dig, and work tool positioner.

Optimized Machine Capability

Maximize machine capability and control with the available Advanced Display, providing on-screen adjustments for implement response, hystat response and creep control. Also features multi-language functionality with customizable layouts, security system and rearview camera.

Sustainability

The Cat® C2.2 engine meets U.S. EPA Tier 4 Final and EU Stage V emission standards.
Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester). Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details.
Cat® Extended Life Coolant and long-life HYDO Advanced hydraulic fluids not only reduce downtime but help decrease the amount of fluid and filters that are replaced over the life of the machine.
Boost productivity with Cat technologies like work tool positioner, return to dig, and Cat Smart Attachments.
Save fuel and reduce your greenhouse gas emissions with efficiency features such as foot throttle pedal and cooling system demand fan.

Equipment Info

ELECTRICAL

12 volt Electrical System

OPERATOR ENVIRONMENT

Gauges: Fuel Level, Hour Meter

POWER TRAIN

Cat C2.2, Turbo Diesel Engine, Meeting Tier 4 Final and Stage V emission standards

OTHER

Engine Enclosure, Lockable

MANDATORY EQUIPMENT

Hydraulics, Standard or High Flow
