1849 mm (73 in), Plate Tine Style

Get in touch

Cat® Skeleton Buckets for Cat Skid Steer Loaders and Compact Track Loaders are designed for removing rocks and larger debris from soil and sand in a variety of applications and materials. These buckets are ideal for agriculture, construction, landscaping, industrial and scrap handling applications.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Width

72.8 in 1849 mm
{"Name":"Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"72.8","MetricUnit":"mm","MetricValue":"1849","Type":"measurement","SpecificationGroup":null,"SortOrder":"1"}
Weight

698.9 lb 317 kg
{"Name":"Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"698.9","MetricUnit":"kg","MetricValue":"317","Type":"measurement","SpecificationGroup":null,"SortOrder":"2"}
Height

21.4 in 544 mm
{"Name":"Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"21.4","MetricUnit":"mm","MetricValue":"544","Type":"measurement","SpecificationGroup":null,"SortOrder":"3"}
Length

43.9 in 1115 mm
{"Name":"Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"43.9","MetricUnit":"mm","MetricValue":"1115","Type":"measurement","SpecificationGroup":null,"SortOrder":"4"}
Sidewall Thickness

0.5 in 12 mm
{"Name":"Sidewall Thickness","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"0.5","MetricUnit":"mm","MetricValue":"12","Type":"measurement","SpecificationGroup":null,"SortOrder":"5"}
Tine Spacing

2.9 in 73 mm
{"Name":"Tine Spacing","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"2.9","MetricUnit":"mm","MetricValue":"73","Type":"measurement","SpecificationGroup":null,"SortOrder":"6"}
Tine Thickness

0.4 in 10 mm
{"Name":"Tine Thickness","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"0.4","MetricUnit":"mm","MetricValue":"10","Type":"measurement","SpecificationGroup":null,"SortOrder":"7"}
Number of Tines

21
{"Name":"Number of Tines","SpecificationId":null,"TextValue":"21","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"8"}
Interface Type

Skid Steer Coupler
{"Name":"Interface Type","SpecificationId":null,"TextValue":"Skid Steer Coupler","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"9"}

Benefits

Application

Designed for screening debris from finer materials such as sand and loose soil, and for reclaiming rock and landscaping materials buried by sediment. Cat® Skeleton buckets are for use on both Cat Skid Steer Loaders and Compact Track Loaders.

Plate Tine Style Bucket

Plate tines are 10 mm (0.4 in) in thickness with fishhook style tine points for better soil penetration to remove roots and reclaim construction material left on the jobsite.

Rock Dam

Rock dam improves material retention, reduces spillage and increases productivity.

Serrated Step

Serrated step ensures operator stability for entering and exiting the cab.

Wide Tine Spacing

Wide tine spacing allows for quicker screening and greater material separation.
