BD121 Sand

Get in touch

Cat® Side Discharge Buckets for Cat Skid Steer Loaders, Compact Track Loaders and Compact Wheel Loaders are designed to handle a variety of material management and aggregate distribution needs. The left or right discharge design eliminates the need for awkward maneuvering, saving time. Spread material in forward or reverse, left or right and get into the tightest areas of your operation.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Capacity

1.3 yd³ 1.02 m³
{"Name":"Capacity","SpecificationId":null,"TextValue":null,"EnglishUnit":"yd³","EnglishValue":"1.3","MetricUnit":"m³","MetricValue":"1.02","Type":"measurement","SpecificationGroup":null,"SortOrder":"1"}
Width

85.2 in 2165 mm
{"Name":"Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"85.2","MetricUnit":"mm","MetricValue":"2165","Type":"measurement","SpecificationGroup":null,"SortOrder":"2"}
Required Hydraulics

Standard Flow
{"Name":"Required Hydraulics","SpecificationId":null,"TextValue":"Standard Flow","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"3"}
Weight

1150.8 lb 522 kg
{"Name":"Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"1150.8","MetricUnit":"kg","MetricValue":"522","Type":"measurement","SpecificationGroup":null,"SortOrder":"4"}
Height

34.1 in 867 mm
{"Name":"Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"34.1","MetricUnit":"mm","MetricValue":"867","Type":"measurement","SpecificationGroup":null,"SortOrder":"5"}
Length

50 in 1269 mm
{"Name":"Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"50","MetricUnit":"mm","MetricValue":"1269","Type":"measurement","SpecificationGroup":null,"SortOrder":"6"}
Optimal Hydraulic Flow

76-87 lpm (20-23 gpm)
{"Name":"Optimal Hydraulic Flow","SpecificationId":null,"TextValue":"76-87 lpm (20-23 gpm)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"7"}
Optimal Hydraulic Pressure

130-230 bar (2000-3300 psi)
{"Name":"Optimal Hydraulic Pressure","SpecificationId":null,"TextValue":"130-230 bar (2000-3300 psi)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"8"}
Belt Width

12 in 305 mm
{"Name":"Belt Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"12","MetricUnit":"mm","MetricValue":"305","Type":"measurement","SpecificationGroup":null,"SortOrder":"9"}
Interface Type

Skid Steer Coupler
{"Name":"Interface Type","SpecificationId":null,"TextValue":"Skid Steer Coupler","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"10"}
Overall Width

86.9 in 2206 mm
{"Name":"Overall Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"86.9","MetricUnit":"mm","MetricValue":"2206","Type":"measurement","SpecificationGroup":null,"SortOrder":"11"}

Benefits

Application

Designed to collect and discharge sawdust, mulch, straw and sand into barns, stalls and orchards, backfill top soil or pea gravel into trenches and spread silage.

Manually Adjustable Discharge Doors

Manually adjustable discharge doors on both sides regulate the volume of discharged material. Thick plating reinforces the doors for long lasting performance.

Dual Direction Rubber Conveyor Belt

Dual direction rubber conveyor belt is heavy-duty with a raised chevron tread and adjustable tension belt. Dual direction drive boosts productivity by eliminating the need for awkward maneuvering commonly encountered in tight areas.

High Torque Agitator

High torque agitator assembly is directly powered by an independent hydraulic motor. Motor and conveyor systems rotate in conjunction on bi-axis planes for consistent flow and to prevent material from bridging inside the bucket.

Dual Direct Drive Hydraulic Motors

Dual direct drive hydraulic motors drive the belt and a third motor drives the agitator providing consistent hydraulic flow. Motors are externally mounted for convenient access.

Welded-On Serrated Safety Step

Welded-on serrated safety step allows for easy entry and exit from the cab.

Tool Mounted Operation and Maintenance Manual

Tool mounted operation and maintenance manual required for proper operation of the work tool attachment is sealed from the elements.
