0.9 m3 (1.2 yd3), HPL-V Coupler, Bolt-On Cutting Edge

Get in touch

Cat® Multi-Purpose Buckets have the same loading, reliability and durability characteristics as other Compact Wheel Loader buckets, with the added versatility for digging, dozing, clamping, grading and leveling in a broad range of applications.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Width

81.1 in 2060 mm
{"Name":"Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"81.1","MetricUnit":"mm","MetricValue":"2060","Type":"measurement","SpecificationGroup":null,"SortOrder":"1"}
Weight

1397.7 lb 634 kg
{"Name":"Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"1397.7","MetricUnit":"kg","MetricValue":"634","Type":"measurement","SpecificationGroup":null,"SortOrder":"2"}
Height

37.4 in 949 mm
{"Name":"Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"37.4","MetricUnit":"mm","MetricValue":"949","Type":"measurement","SpecificationGroup":null,"SortOrder":"3"}
Length

36.5 in 926 mm
{"Name":"Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"36.5","MetricUnit":"mm","MetricValue":"926","Type":"measurement","SpecificationGroup":null,"SortOrder":"4"}
Capacity

1.2 yd³ 0.9 m³
{"Name":"Capacity","SpecificationId":null,"TextValue":null,"EnglishUnit":"yd³","EnglishValue":"1.2","MetricUnit":"m³","MetricValue":"0.9","Type":"measurement","SpecificationGroup":null,"SortOrder":"5"}
Jaw Opening

29.3 in 743 mm
{"Name":"Jaw Opening","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"29.3","MetricUnit":"mm","MetricValue":"743","Type":"measurement","SpecificationGroup":null,"SortOrder":"6"}
Clam Angle

87 degrees
{"Name":"Clam Angle","SpecificationId":null,"TextValue":"87 degrees","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"7"}
Base Edge Thickness

0.8 in 20 mm
{"Name":"Base Edge Thickness","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"0.8","MetricUnit":"mm","MetricValue":"20","Type":"measurement","SpecificationGroup":null,"SortOrder":"8"}
Cutting Edge Thickness

0.6 in 16 mm
{"Name":"Cutting Edge Thickness","SpecificationId":null,"TextValue":"ISO Coupler","EnglishUnit":"in","EnglishValue":"0.6","MetricUnit":"mm","MetricValue":"16","Type":"measurement","SpecificationGroup":null,"SortOrder":"9"}
Interface Type

HPL-V Coupler
{"Name":"Interface Type","SpecificationId":null,"TextValue":"HPL-V Coupler","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"10"}

Benefits

Application

Ideal for digging, dozing, clamping, back dragging, grading and leveling in construction, landscaping, industrial and demolition applications.

Added Versatility

Excellent clamping force lets you grasp large, irregularly shaped objects such as trees, loose stumps, brush, recycling debris and pipe, increasing the versatility of the machine.

Dozing Application

Bucket clam jaw opening allows the bucket to be used as a dozing blade.

Serrated Clam Edge

Serrated clam side edge provides a gripping surface to hold material.

Ground Engaging Tool Options

Base bucket also available with bolt-on cutting edge and bolt-on teeth.
