Specifications

Body Hoists

Type

Twin, two-stage hydraulic cylinders with snubbing valve.
{"Name":"Type","SpecificationId":null,"TextValue":"Twin, two-stage hydraulic cylinders with snubbing valve.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Body Hoists","SortOrder":"47"}
Pump Flow - High Idle

106.5 gpm 403 L/min
{"Name":"Pump Flow - High Idle","SpecificationId":null,"TextValue":null,"EnglishUnit":"gpm","EnglishValue":"106.5","MetricUnit":"L/min","MetricValue":"403","Type":"measurement","SpecificationGroup":"Body Hoists","SortOrder":"48"}
Relief Valve Setting - Raise

2749 psi 18950 kPa
{"Name":"Relief Valve Setting - Raise","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"2749","MetricUnit":"kPa","MetricValue":"18950","Type":"measurement","SpecificationGroup":"Body Hoists","SortOrder":"49"}
Body Raise Time - High Idle

14 s 14 s
{"Name":"Body Raise Time - High Idle","SpecificationId":null,"TextValue":null,"EnglishUnit":"s","EnglishValue":"14","MetricUnit":"s","MetricValue":"14","Type":"measurement","SpecificationGroup":"Body Hoists","SortOrder":"50"}
Body Lower Time - Float

16 s 16 s
{"Name":"Body Lower Time - Float","SpecificationId":null,"TextValue":null,"EnglishUnit":"s","EnglishValue":"16","MetricUnit":"s","MetricValue":"16","Type":"measurement","SpecificationGroup":"Body Hoists","SortOrder":"51"}

Braking System

Service Brakes

Four-Corner, Wet Disc, Oil Cooled, Hydraulically Actuated
{"Name":"Service Brakes","SpecificationId":null,"TextValue":"Four-Corner, Wet Disc, Oil Cooled, Hydraulically Actuated","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Braking System","SortOrder":"39"}
Front Wet Disc Brake Surface Area

12662 in² 81693 cm²
{"Name":"Front Wet Disc Brake Surface Area","SpecificationId":null,"TextValue":null,"EnglishUnit":"in²","EnglishValue":"12662","MetricUnit":"cm²","MetricValue":"81693","Type":"measurement","SpecificationGroup":"Braking System","SortOrder":"40"}
Rear - Wet Disc Brake Surface Area

20861 in² 134590 cm²
{"Name":"Rear - Wet Disc Brake Surface Area","SpecificationId":null,"TextValue":null,"EnglishUnit":"in²","EnglishValue":"20861","MetricUnit":"cm²","MetricValue":"134590","Type":"measurement","SpecificationGroup":"Braking System","SortOrder":"41"}
Standards

(Service and Secondary) ISO 3450:2011
{"Name":"Standards","SpecificationId":null,"TextValue":"(Service and Secondary) ISO 3450:2011","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Braking System","SortOrder":"42"}
Parking Brake

Four-corner, Multi-disc, Spring applied, Hydraulically Released
{"Name":"Parking Brake","SpecificationId":null,"TextValue":"Four-corner, Multi-disc, Spring applied, Hydraulically Released","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Braking System","SortOrder":"43"}

Cab

Air Conditioning

(HFC - 134A refrigerant) 24,500 Btu/hr
{"Name":"Air Conditioning","SpecificationId":null,"TextValue":"(HFC - 134A refrigerant) 24,500 Btu/hr","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Cab","SortOrder":"69"}
Heater / Defroster

33300 Btu/h 33300 Btu/h
{"Name":"Heater / Defroster","SpecificationId":null,"TextValue":null,"EnglishUnit":"Btu/h","EnglishValue":"33300","MetricUnit":"Btu/h","MetricValue":"33300","Type":"measurement","SpecificationGroup":"Cab","SortOrder":"70"}
FOPS Standards

FOPS (Falling Objects Protective Structure) meets ISO 3449:2005 Level II for Operator and ISO 13459:2012 Level II for Trainer.
{"Name":"FOPS Standards","SpecificationId":null,"TextValue":"FOPS (Falling Objects Protective Structure) meets ISO 3449:2005 Level II for Operator and ISO 13459:2012 Level II for Trainer.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Cab","SortOrder":"72"}
ROPS Standards (2)

ROPS (Rollover Protective Structure) meets ISO 3471:2008 for Operator and ISO 13459:2012 for Trainer.
{"Name":"ROPS Standards (2)","SpecificationId":null,"TextValue":"ROPS (Rollover Protective Structure) meets ISO 3471:2008 for Operator and ISO 13459:2012 for Trainer.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Cab","SortOrder":"73"}

Capacity - HP Body - 100% Fill Factor

Struck

77 m3(101 yd3)
{"Name":"Struck","SpecificationId":null,"TextValue":"77 m3(101 yd3)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Capacity - HP Body - 100% Fill Factor","SortOrder":"44"}
Heaped (SAE 2:1)*

187
{"Name":"Heaped (SAE 2:1)*","SpecificationId":null,"TextValue":"187","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Capacity - HP Body - 100% Fill Factor","SortOrder":"45"}
Note (1)

Consult your local Cat dealer for body recommendations
{"Name":"Note (1)","SpecificationId":null,"TextValue":"Consult your local Cat dealer for body recommendations","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Capacity - HP Body - 100% Fill Factor","SortOrder":"46"}

Dimensions (Approximate)

Height - Top of ROPS

5550 mm 18.25 ft
{"Name":"Height - Top of ROPS","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"5550","MetricUnit":"ft","MetricValue":"18.25","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"77"}
Overall Body Length

12945 mm 42.5 ft
{"Name":"Overall Body Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"12945","MetricUnit":"ft","MetricValue":"42.5","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"78"}
Inside Body Length

8730 mm 28.67 ft
{"Name":"Inside Body Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"8730","MetricUnit":"ft","MetricValue":"28.67","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"79"}
Overall Length

12970 mm 42.58 ft
{"Name":"Overall Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"12970","MetricUnit":"ft","MetricValue":"42.58","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"80"}
Wheel Base

57000 mm 18.67 ft
{"Name":"Wheel Base","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"57000","MetricUnit":"ft","MetricValue":"18.67","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"81"}
Rear Axle - Tail

3856 mm 12.67 ft
{"Name":"Rear Axle - Tail","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"3856","MetricUnit":"ft","MetricValue":"12.67","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"82"}
Ground Clearance

1304 mm 4.25 ft
{"Name":"Ground Clearance","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"1304","MetricUnit":"ft","MetricValue":"4.25","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"83"}
Dump Clearance

1585 mm 5.17 ft
{"Name":"Dump Clearance","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"1585","MetricUnit":"ft","MetricValue":"5.17","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"84"}
Loading Height - Empty

6147 mm 20.17 ft
{"Name":"Loading Height - Empty","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"6147","MetricUnit":"ft","MetricValue":"20.17","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"85"}
Rear Sidewall Height

1010 mm 3.33 ft
{"Name":"Rear Sidewall Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"1010","MetricUnit":"ft","MetricValue":"3.33","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"86"}
Inside Body Depth - Maximum

3075 mm 10.08 ft
{"Name":"Inside Body Depth - Maximum","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"3075","MetricUnit":"ft","MetricValue":"10.08","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"87"}
Overall Height - Body Raised

11534 mm 37.83 ft
{"Name":"Overall Height - Body Raised","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"11534","MetricUnit":"ft","MetricValue":"37.83","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"88"}
Operating Width

7822 mm 25.67 ft
{"Name":"Operating Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"7822","MetricUnit":"ft","MetricValue":"25.67","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"89"}
Centerline Front Tire Width

5410 mm 17.75 ft
{"Name":"Centerline Front Tire Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"5410","MetricUnit":"ft","MetricValue":"17.75","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"90"}
Engine Guard Clearance

1290 mm 4.25 ft
{"Name":"Engine Guard Clearance","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"1290","MetricUnit":"ft","MetricValue":"4.25","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"91"}
Overall Canopy Width

7769 mm 25.5 ft
{"Name":"Overall Canopy Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"7769","MetricUnit":"ft","MetricValue":"25.5","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"92"}
Outside Body Width

7123 mm 23.33 ft
{"Name":"Outside Body Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"7123","MetricUnit":"ft","MetricValue":"23.33","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"93"}
Inside Body Width

6920 mm 22.67 ft
{"Name":"Inside Body Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"6920","MetricUnit":"ft","MetricValue":"22.67","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"94"}
Front Canopy Height

6739 mm 22.08 ft
{"Name":"Front Canopy Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"6739","MetricUnit":"ft","MetricValue":"22.08","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"95"}
Rear Axle - Clearance

1263 mm 4.17 ft
{"Name":"Rear Axle - Clearance","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"1263","MetricUnit":"ft","MetricValue":"4.17","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"96"}
Centerline of Rear Dual Tire Width

4695 mm 15.42 ft
{"Name":"Centerline of Rear Dual Tire Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"4695","MetricUnit":"ft","MetricValue":"15.42","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"97"}
Overall Tire Width

7120 mm 23.33 ft
{"Name":"Overall Tire Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"mm","EnglishValue":"7120","MetricUnit":"ft","MetricValue":"23.33","Type":"measurement","SpecificationGroup":"Dimensions (Approximate)","SortOrder":"98"}

Engine

Gross Power - SAE J1995:2014

2100 hp 1566 kW
{"Name":"Gross Power - SAE J1995:2014","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"2100","MetricUnit":"kW","MetricValue":"1566","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"3"}
Engine Model

Cat® 3516E
{"Name":"Engine Model","SpecificationId":null,"TextValue":"Cat® 3516E","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"4"}
Net Power - SAE J1349:2011

1975 hp 1473 kW
{"Name":"Net Power - SAE J1349:2011","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"1975","MetricUnit":"kW","MetricValue":"1473","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"5"}
Rated Speed

1650 r/min 1650 r/min
{"Name":"Rated Speed","SpecificationId":null,"TextValue":null,"EnglishUnit":"r/min","EnglishValue":"1650","MetricUnit":"r/min","MetricValue":"1650","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"6"}
Emissions Rating

Fuel Optimized
{"Name":"Emissions Rating","SpecificationId":null,"TextValue":"Fuel Optimized","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"7"}
Bore

6.7 in 170 mm
{"Name":"Bore","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"6.7","MetricUnit":"mm","MetricValue":"170","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"8"}
Stroke

8.5 in 215 mm
{"Name":"Stroke","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"8.5","MetricUnit":"mm","MetricValue":"215","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"9"}
Displacement

4766 in³ 7.8 l
{"Name":"Displacement","SpecificationId":null,"TextValue":null,"EnglishUnit":"in³","EnglishValue":"4766","MetricUnit":"l","MetricValue":"7.8","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"10"}
Note (1)

Net Power advertised is the power available at the flywheel when the engine is equipped with air intake system, exhaust system, and alternator.
{"Name":"Note (1)","SpecificationId":null,"TextValue":"Net Power advertised is the power available at the flywheel when the engine is equipped with air intake system, exhaust system, and alternator.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"11"}
Note (2)

Optional 1417 kW / 1,900 HP engine rating.
{"Name":"Note (2)","SpecificationId":null,"TextValue":"Optional 1417 kW / 1,900 HP engine rating.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"12"}
Note (3)

U.S. EPA Tier 4 Final / EU Stage V optional engine available for applicable markets.
{"Name":"Note (3)","SpecificationId":null,"TextValue":"U.S. EPA Tier 4 Final / EU Stage V optional engine available for applicable markets.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"13"}

Final Drives

Planetary Ratio

10.83:1
{"Name":"Planetary Ratio","SpecificationId":null,"TextValue":"10.83:1","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Final Drives","SortOrder":"23"}
Total Reduction Ratio

25.46:1
{"Name":"Total Reduction Ratio","SpecificationId":null,"TextValue":"25.46:1","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Final Drives","SortOrder":"24"}
Type

Double reduction, planetary with full floating axles
{"Name":"Type","SpecificationId":null,"TextValue":"Double reduction, planetary with full floating axles","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Final Drives","SortOrder":"25"}
Differential Ratio

2.35:1
{"Name":"Differential Ratio","SpecificationId":null,"TextValue":"2.35:1","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Final Drives","SortOrder":"26"}

Service Refill Capacities

Fuel Tank - Standard

550 gal (US) 2500 l
{"Name":"Fuel Tank - Standard","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"550","MetricUnit":"l","MetricValue":"2500","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"56"}
Fuel Tank

1000 gal (US) 4546 l
{"Name":"Fuel Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"1000","MetricUnit":"l","MetricValue":"4546","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"57"}
Fuel Tank (Tier 4)

55 gal (US) 2500 l
{"Name":"Fuel Tank (Tier 4)","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"55","MetricUnit":"l","MetricValue":"2500","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"58"}
Diesel Exhaust Fluid Tank

62 gal (US) 233 l
{"Name":"Diesel Exhaust Fluid Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"62","MetricUnit":"l","MetricValue":"233","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"59"}
Cooling System

180 gal (US) 679 l
{"Name":"Cooling System","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"180","MetricUnit":"l","MetricValue":"679","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"60"}
Crankcase

77 gal (US) 291 l
{"Name":"Crankcase","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"77","MetricUnit":"l","MetricValue":"291","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"61"}
Front Wheels - Each

5.8 gal (US) 22 l
{"Name":"Front Wheels - Each","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"5.8","MetricUnit":"l","MetricValue":"22","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"62"}
Differentials

161 gal (US) 610 l
{"Name":"Differentials","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"161","MetricUnit":"l","MetricValue":"610","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"63"}
Steering System

42 gal (US) 160 l
{"Name":"Steering System","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"42","MetricUnit":"l","MetricValue":"160","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"64"}
Steering System - Includes Tank

46 gal (US) 175 l
{"Name":"Steering System - Includes Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"46","MetricUnit":"l","MetricValue":"175","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"65"}
Brake Hoist System

169 gal (US) 640 l
{"Name":"Brake Hoist System","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"169","MetricUnit":"l","MetricValue":"640","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"66"}
Brake Hoist System - Includes Tank

347 gal (US) 1315 l
{"Name":"Brake Hoist System - Includes Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"347","MetricUnit":"l","MetricValue":"1315","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"67"}
Torque Converter - Transmission System - Including Sump

55 gal (US) 209 l
{"Name":"Torque Converter - Transmission System - Including Sump","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"55","MetricUnit":"l","MetricValue":"209","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"68"}

Sound

Sound Standards (1)

Operator sound pressure level, 77 dB(A) with direct drive and 75 dB(A) with optional clutch, tested to ISO 6396:2008.
{"Name":"Sound Standards (1)","SpecificationId":null,"TextValue":"Operator sound pressure level, 77 dB(A) with direct drive and 75 dB(A) with optional clutch, tested to ISO 6396:2008.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Sound","SortOrder":"101"}

Steering

Steer Angle

36.07 ° 36.07 °
{"Name":"Steer Angle","SpecificationId":null,"TextValue":null,"EnglishUnit":"°","EnglishValue":"36.07","MetricUnit":"°","MetricValue":"36.07","Type":"measurement","SpecificationGroup":"Steering","SortOrder":"74"}
Steering Standards

ISO 5010:2019
{"Name":"Steering Standards","SpecificationId":null,"TextValue":"ISO 5010:2019","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Steering","SortOrder":"75"}

Suspension

Type

Self-contained nitrogen/oil cylinders, pin-to-pin mounting, top and bottom double shear clevis attachments
{"Name":"Type","SpecificationId":null,"TextValue":"Self-contained nitrogen/oil cylinders, pin-to-pin mounting, top and bottom double shear clevis attachments","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Suspension","SortOrder":"52"}
Effective Cylinder Stroke - Front

4.12 in 104.65 mm
{"Name":"Effective Cylinder Stroke - Front","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"4.12","MetricUnit":"mm","MetricValue":"104.65","Type":"measurement","SpecificationGroup":"Suspension","SortOrder":"53"}
Effective Cylinder Stroke - Rear

3.67 in 93.22 mm
{"Name":"Effective Cylinder Stroke - Rear","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"3.67","MetricUnit":"mm","MetricValue":"93.22","Type":"measurement","SpecificationGroup":"Suspension","SortOrder":"54"}
Rear axle - Oscillation

+/- 5 degrees
{"Name":"Rear axle - Oscillation","SpecificationId":null,"TextValue":"+/- 5 degrees","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Suspension","SortOrder":"55"}

Tires

Standard Tires

37 R57
{"Name":"Standard Tires","SpecificationId":null,"TextValue":"37 R57","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Tires","SortOrder":"33"}
Optional Tires

40 R57
{"Name":"Optional Tires","SpecificationId":null,"TextValue":"40 R57","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Tires","SortOrder":"34"}
Optional Tire

42/90 R57
{"Name":"Optional Tire","SpecificationId":null,"TextValue":"42/90 R57","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Tires","SortOrder":"35"}
Rims

29” x 57” Rims
{"Name":"Rims","SpecificationId":null,"TextValue":"29” x 57” Rims","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Tires","SortOrder":"36"}
Note (1)

Quick Change Rims optional
{"Name":"Note (1)","SpecificationId":null,"TextValue":"Quick Change Rims optional","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Tires","SortOrder":"37"}
Note (2)

Caterpillar recommends the customer evaluate all job conditions and consult tire manufacturer for proper tire selection and TKPH (TMPH) capabilities.
{"Name":"Note (2)","SpecificationId":null,"TextValue":"Caterpillar recommends the customer evaluate all job conditions and consult tire manufacturer for proper tire selection and TKPH (TMPH) capabilities.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Tires","SortOrder":"38"}

Transmission

Forward - 1

7.8 mile/h 12.6 km/h
{"Name":"Forward - 1","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"7.8","MetricUnit":"km/h","MetricValue":"12.6","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"25"}
Forward - 2

10.6 mile/h 17.1 km/h
{"Name":"Forward - 2","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"10.6","MetricUnit":"km/h","MetricValue":"17.1","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"26"}
Forward - 3

14.4 mile/h 23.1 km/h
{"Name":"Forward - 3","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"14.4","MetricUnit":"km/h","MetricValue":"23.1","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"27"}
Forward - 4

19.4 mile/h 31.2 km/h
{"Name":"Forward - 4","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"19.4","MetricUnit":"km/h","MetricValue":"31.2","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"28"}
Forward - 5

26.3 mile/h 42.3 km/h
{"Name":"Forward - 5","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"26.3","MetricUnit":"km/h","MetricValue":"42.3","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"29"}
Forward - 6

35.5 mile/h 57.2 km/h
{"Name":"Forward - 6","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"35.5","MetricUnit":"km/h","MetricValue":"57.2","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"30"}
Reverse

7.3 mile/h 11.8 km/h
{"Name":"Reverse","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"7.3","MetricUnit":"km/h","MetricValue":"11.8","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"31"}
Top Speed - Loaded

35.5 mile/h 57.2 km/h
{"Name":"Top Speed - Loaded","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"35.5","MetricUnit":"km/h","MetricValue":"57.2","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"32"}

Weight Distributions - Approximate

Front Axle - Empty

50%
{"Name":"Front Axle - Empty","SpecificationId":null,"TextValue":"50%","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Weight Distributions - Approximate","SortOrder":"20"}
Rear Axle - Loaded

67%
{"Name":"Rear Axle - Loaded","SpecificationId":null,"TextValue":"67%","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Weight Distributions - Approximate","SortOrder":"21"}
Rear Axle - Empty

50%
{"Name":"Rear Axle - Empty","SpecificationId":null,"TextValue":"50%","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Weight Distributions - Approximate","SortOrder":"23"}
Front Axle - Loaded

33%
{"Name":"Front Axle - Loaded","SpecificationId":null,"TextValue":"33%","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Weight Distributions - Approximate","SortOrder":"24"}

Weights - Approximate

Nominal Rated Payload

213 ton (US) 193 t
{"Name":"Nominal Rated Payload","SpecificationId":null,"TextValue":null,"EnglishUnit":"ton (US)","EnglishValue":"213","MetricUnit":"t","MetricValue":"193","Type":"measurement","SpecificationGroup":"Weights - Approximate","SortOrder":"1"}
Rated Gross Machine Weight

715000 lb 324318 kg
{"Name":"Rated Gross Machine Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"715000","MetricUnit":"kg","MetricValue":"324318","Type":"measurement","SpecificationGroup":"Weights - Approximate","SortOrder":"2"}
Body Weight

60406 lb 27400 kg
{"Name":"Body Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"60406","MetricUnit":"kg","MetricValue":"27400","Type":"measurement","SpecificationGroup":"Weights - Approximate","SortOrder":"15"}
Note (1)

Consult your tire manufacturer for maximum tire load
{"Name":"Note (1)","SpecificationId":null,"TextValue":"Consult your tire manufacturer for maximum tire load","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Weights - Approximate","SortOrder":"17"}
Note (2)

Chassis weight with full fuel and fluids, standard and mandatory attachments, hoist, body mounting group, rims, and tires.
{"Name":"Note (2)","SpecificationId":null,"TextValue":"Chassis weight with full fuel and fluids, standard and mandatory attachments, hoist, body mounting group, rims, and tires.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Weights - Approximate","SortOrder":"18"}

Benefits

PRODUCTIVITY

The 789 delivers a faster speed on grade than competitive trucks thanks to the efficient 3516E 16-cylinder engine and mechanical drivetrain.
Expanded tire options allow mines to take advantage of higher speeds, particularly in flat, long-haul, high-speed applications.
The Advanced Power Electronic Control Strategy (APECS) enables faster cycle times and faster acceleration thanks to more continuous torque and rimpull.
The 789 has an empty machine weight advantage, allowing it to haul more with every load, delivering a cost per ton advantage over competitive trucks.
Productivity-enhancing features such as Hill Start Assist with Anti-Rollback, Enhanced Traction Control, Dynamic Stability Control (DSC), Anti-lock Brake System (ABS), Machine Speed Limiting and Cruise Control improve machine responsiveness and controllability while improving cycle times and reducing operator fatigue.

SAFETY

Wide, slip-resistant surfaces and hand rails, plus an optional powered access ladder, improve access and egress.
Superior control is delivered by a patented braking system that provides immediate, fade-resistant braking and retarding.
Visibility is enhanced by wide-angle mirrors plus an optional 360-degree Surround View camera, which offers a bird’s-eye view.
The Cat MineStar™ Object Detection system combines radar and camera systems to warn operators about light vehicles or stationary hazards within the immediate vicinity of their machines.
The optional Driver Safety System alerts the operator if fatigue or distraction are detected.

OPERATOR COMFORT

The cab provides 34% more operator space than D-Series models. It’s 17% wider and offers 11% more legroom and 19% more shoulder room.
Controls, levers and switches are positioned for ease of use.
With 40% less Sound Pressure Level (SPL), automated temperature control and cab filtration, operators enjoy a safer and more comfortable environment.
A walkthrough cab with fully adjustable center console, easy-to-adjust seat and increased leg room make the cab ideal for operators of all sizes.
The next generation seat is four-point-restraint ready and incorporates features like thigh tilt and extensions, air adjustable side and lumbar bolsters, and heated and cooled cushions.

OPERATOR EFFICIENCY & PRODUCTIVITY

Higher resolution displays improve access to information. Machine data, controls and guidance information are consolidated onto two 10-inch screens.
The optional Auto Hoist feature automatically raises the body and controls engine speed, simplifying operation and minimizing cycle times.
Speed coaching gives operators real-time feedback on how to operate the truck to maximize its productivity.
The payload monitoring system comes with more accurate measurements, providing immediate feedback to the operator.

SERVICEABILITY

The new modular HVAC (heating, ventilation and air conditioning) system improves reliability and consolidates components so the entire system can be removed and replaced quickly.
A modular radiator reduces engine removal and installation time and enables rebuilds to be completed off the truck.
New remote flash and remote troubleshooting capabilities provide immediate access to the latest software updates and make it possible to troubleshoot the machine remotely.
Time spent on regular maintenance procedures is reduced thanks to features such as extended service intervals; ground-level access to tanks, filters, drains and engine shutdown; easier access to daily service points as well as major components; a maintenance platform with access to the engine; and optional fast-fill service center.
A 100% airless electric start option eliminates air system maintenance from the machine and improves uptime.

DURABILITY AND LONG LIFE

The 789 frame uses a box-section design, incorporating two forgings and 21 castings in high-stress areas with deep penetrating and continuous wrap-around welds to resist damage from twisting loads without adding extra weight. The mild steel frame provides flexibility, durability and resistance to impact loads.
Resiliently mounted to the main frame to reduce vibration and sound, the integral ROPS is designed as an extension of the truck frame.
Component life is enhanced thanks to the standard rear-axle continuous filtration feature. Cleaner oil helps promote lubrication that leads to longer life
The frame, powertrain, engine and components are built to be rebuilt — delivering multiple lives of like-new performance at a fraction-of-new price.

CAT BODIES

Cat bodies are the best choice for the 789. They’re designed to be an integral part of the entire vehicle system, ensuring you achieve maximum chassis life.
The High Performance (HP) body features a lightweight, simplified and durable design that provides complete front machine coverage and extended overhead protection.
Available in several sizes, the MSD II body is ideal for mature mines with good operational and maintenance practices. It can be lined or unlined, with a site-specific body designed to maximize performance.
Intended for tough applications including greenfield sites and contracting mines, the Dual Slope body provides excellent load retention, maintains a low center of gravity with optimum load distribution and reduces shock loading.
The X Body incorporates the latest structural designs and offers more volume at a lower weight. It uses the Cat Mine Specific Design to create a body that is properly sized to meet the specific requirements of heavy-duty applications.

SUSTAINABILITY

The 789 is designed to use less fuel, which reduces engine emissions, and there is zero fuel burn during retarding. The Tier 4 Final engine reduces NOx and particulate matter.
The Cat 3516E provides emission choices: fuel-optimized engine for less regulated countries or optional engine compliant to U.S. EPA Tier 4 Final / EU Stage V emissions standards.
The 789 engine is compatible with diesel fuel blended with lower-carbon intensity fuels such as biofuels and renewable fuels.
Features like oil renewal systems, continuous rear axle filtration, extended life filters and longer maintenance intervals decrease the amount of waste contributed to the environment.
By rebuilding machines and components, the Cat Rebuild and Cat Reman programs preserve raw materials, conserve energy and reduce emissions.

VERSATILITY

The Cat 3516E engine has proven its ability to deliver high power and reliability in the most demanding mining applications.
The mechanical drive powertrain and power shift transmission provide unmatched efficiency and control on steep grades, in poor underfoot conditions and on haul roads with high rolling resistance.
Application-specific capabilities are available for extreme ambient conditions and high-altitude applications.
The 789 lets you select the tire offering that best matches your application, with a larger tire for flat, long, high-speed applications. The frame is designed to maintain the same turning diameter while accommodating larger tires.
The 789 is available in two options to meet the emissions standards. The optional Tier 4 Final engine meets the strictest standards while the LRC engine is available in those countries that are less regulated.

TECHNOLOGY SOLUTIONS

MineStar Fleet is a fleet monitoring system that can be used to measure, manage and maximize the overall hauling operation.
Additional Detect offerings include Awareness, which can provide warnings and the in-cab Driver Safety System, which intervenes when it detects fatigue or distraction.
Machine health and condition monitoring solutions enable a proactive approach to maintenance.

Equipment Info

ELECTRICAL

24V electrical system, low maintenance batteries (2) 93 amp-hour

FLUIDS

Extended Life Coolant to — 35° C (— 30° F)

OPERATOR ENVIRONMENT

5V USB charging port

POWER TRAIN

37R57 standard rims

OTHER EQUIPMENT

Auxiliary "buddy" dumping quick connect

Cat Technology Products

Cyber security

Product Brochures

Product Brochure #1

Product Brochure #2

Product Brochure #3

Product Brochure #4

The Toromont Cat advantage

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Sed eros justo, volutpat sed sem vel, tincidunt dictum ex. Curabitur eget massa nec enim viverra fermentum vel eu ligula.

Lorem ipsum dolor sit amet, consectetur adipiscing elit

Lorem ipsum dolor

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Sed eros justo, volutpat sed sem vel, tincidunt dictum ex.

Learn more

Contact an equipment specialist

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Sed eros justo, volutpat sed sem vel, tincidunt dictum ex. Curabitur eget massa nec enim viverra fermentum vel eu ligula.

Insert form

Lorem ipsum dolor

Learn more

Lorem ipsum dolor

Learn more

Lorem ipsum dolor

Learn more

Lorem ipsum dolor

Learn more

Lorem ipsum dolor

Learn more

Lorem ipsum dolor

Learn more

Excavators

789

789

PRODUCTIVITY

SAFETY

OPERATOR COMFORT

OPERATOR EFFICIENCY & PRODUCTIVITY

SERVICEABILITY

DURABILITY AND LONG LIFE

CAT BODIES

SUSTAINABILITY

VERSATILITY

TECHNOLOGY SOLUTIONS

ELECTRICAL

FLUIDS

OPERATOR ENVIRONMENT

POWER TRAIN

OTHER EQUIPMENT

Cat Technology Products

The Toromont Cat advantage

Lorem ipsum dolor

Contact an equipment specialist

Lorem ipsum dolor

Lorem ipsum dolor

Lorem ipsum dolor

Lorem ipsum dolor

Lorem ipsum dolor

Lorem ipsum dolor
