LT118

Get in touch

Cat® Landscape Tillers are designed for breaking up and pulverizing soil, mixing compost or other materials into existing soil, and stabilizing and leveling existing terrain in landscape finish applications. They are ideal for residential, commercial, agricultural, building construction, lawn care and golf course maintenance applications.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Working Width

72.8 in 1848 mm
{"Name":"Working Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"72.8","MetricUnit":"mm","MetricValue":"1848","Type":"measurement","SpecificationGroup":null,"SortOrder":"1"}
Working Depth

25-152 mm (1-6 in)
{"Name":"Working Depth","SpecificationId":null,"TextValue":"25-152 mm (1-6 in)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"2"}
Weight

925.9 lb 420 kg
{"Name":"Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"925.9","MetricUnit":"kg","MetricValue":"420","Type":"measurement","SpecificationGroup":null,"SortOrder":"3"}
Overall Width

89.4 in 2272 mm
{"Name":"Overall Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"89.4","MetricUnit":"mm","MetricValue":"2272","Type":"measurement","SpecificationGroup":null,"SortOrder":"4"}
Height

29.7 in 755 mm
{"Name":"Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"29.7","MetricUnit":"mm","MetricValue":"755","Type":"measurement","SpecificationGroup":null,"SortOrder":"5"}
Length

37.6 in 956 mm
{"Name":"Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"37.6","MetricUnit":"mm","MetricValue":"956","Type":"measurement","SpecificationGroup":null,"SortOrder":"6"}
Optimal Hydraulic Flow

60-114 L/min (16-30 gpm)
{"Name":"Optimal Hydraulic Flow","SpecificationId":null,"TextValue":"60-114 L/min (16-30 gpm)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"7"}
Optimal Hydraulic Pressure

207-310 bar (3000-4500 psi)
{"Name":"Optimal Hydraulic Pressure","SpecificationId":null,"TextValue":"207-310 bar (3000-4500 psi)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"8"}
Motor Displacement

38.4 in³ 629.09 cm³
{"Name":"Motor Displacement","SpecificationId":null,"TextValue":null,"EnglishUnit":"in³","EnglishValue":"38.4","MetricUnit":"cm³","MetricValue":"629.09","Type":"measurement","SpecificationGroup":null,"SortOrder":"9"}
Drum Speed

127 rpm @ 80 L/min (21 gpm)
{"Name":"Drum Speed","SpecificationId":null,"TextValue":"127 rpm @ 80 L/min (21 gpm)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"10"}
Number of Hard Face Tines

36
{"Name":"Number of Hard Face Tines","SpecificationId":null,"TextValue":"36","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"11"}
Required Hydraulics

Standard Flow
{"Name":"Required Hydraulics","SpecificationId":null,"TextValue":"Standard Flow","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"12"}

Benefits

Application

Designed for breaking up and pulverizing soil, mixing compost or other materials into existing soil, and stabilizing and leveling existing terrain in landscape finish applications.

Direct Drive System

Single motor direct drive system is matched to the machine's auxiliary hydraulic system for maximum performance.

Unique Spiral Tine Arrangement

Unique spiral tine arrangement provides 10% greater cutting performance over tillers with standard placements.

Tungsten Carbide Tines

Tines are hardened for maximum strength, durability and wear life in the toughest soil conditions. The bolt-on design provides quick change versatility and extended work tool life.

Two Full-Width Torque Tubes

Two full-width torque tubes provide rigid structural enforcement of tiller housing. Front torque tube design minimizes hood damage caused from larger rocks.

Arm Level Indicator

Arm level indicator provides operator a visual set-up and operating reference with top tiller attachment arms designed parallel to skid shoe.

Adjustable Skid Shoes

Adjustable and replaceable skid shoes with three position tiller depth adjustment allows for tilling depth to be quickly adjusted without skid shoe removal.

Serrated Steps

Serrated steps provide safe ingress and egress from machine cab.
