BA25 Hydraulic, 12V, Polypropylene/Wire

Get in touch

Cat® Angle Brooms for Skid Steer Loaders, Compact Track Loaders, Backhoe Loaders, Compact Wheel Loaders and Small Wheel Loaders are ideal for clearing parking lots, industrial plants, mill yards, airport runways, streets, driveways and lanes.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Overall Width

106 in 2700 mm
{"Name":"Overall Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"106","MetricUnit":"mm","MetricValue":"2700","Type":"measurement","SpecificationGroup":null,"SortOrder":"1"}
Sweeping Width

98.4 in 2500 mm
{"Name":"Sweeping Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"98.4","MetricUnit":"mm","MetricValue":"2500","Type":"measurement","SpecificationGroup":null,"SortOrder":"2"}
Brush Diameter

27.6 in 700 mm
{"Name":"Brush Diameter","SpecificationId":null,"TextValue":"Standard Flow","EnglishUnit":"in","EnglishValue":"27.6","MetricUnit":"mm","MetricValue":"700","Type":"measurement","SpecificationGroup":null,"SortOrder":"3"}
Required Hydraulics

Standard Flow
{"Name":"Required Hydraulics","SpecificationId":null,"TextValue":"Standard Flow","EnglishUnit":"in","EnglishValue":"51.2","MetricUnit":"mm","MetricValue":"1300","Type":"text","SpecificationGroup":null,"SortOrder":"4"}
Height

51.2 in 1300 mm
{"Name":"Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"51.2","MetricUnit":"mm","MetricValue":"1300","Type":"measurement","SpecificationGroup":null,"SortOrder":"5"}
Length

60.4 in 1535 mm
{"Name":"Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"60.4","MetricUnit":"mm","MetricValue":"1535","Type":"measurement","SpecificationGroup":null,"SortOrder":"6"}
Weight

970 lb 440 kg
{"Name":"Weight","SpecificationId":null,"TextValue":"40-150 L/min (11-40 gpm)","EnglishUnit":"lb","EnglishValue":"970","MetricUnit":"kg","MetricValue":"440","Type":"measurement","SpecificationGroup":null,"SortOrder":"7"}
Optimal Hydraulic Flow

40-150 L/min (11-40 gpm)
{"Name":"Optimal Hydraulic Flow","SpecificationId":null,"TextValue":"40-150 L/min (11-40 gpm)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"8"}
Optimal Hydraulic Pressure

150-260 bar (2176-3771 psi)
{"Name":"Optimal Hydraulic Pressure","SpecificationId":null,"TextValue":"150-260 bar (2176-3771 psi)","EnglishUnit":"in³/rev","EnglishValue":"11.9","MetricUnit":"cm³/rev","MetricValue":"195","Type":"text","SpecificationGroup":null,"SortOrder":"9"}
Motor Displacement

11.9 in³/rev 195 cm³/rev
{"Name":"Motor Displacement","SpecificationId":null,"TextValue":"385 RPM","EnglishUnit":"in³/rev","EnglishValue":"11.9","MetricUnit":"cm³/rev","MetricValue":"195","Type":"measurement","SpecificationGroup":null,"SortOrder":"10"}
Brush Speed at Maximum Flow

385 RPM
{"Name":"Brush Speed at Maximum Flow","SpecificationId":null,"TextValue":"385 RPM","EnglishUnit":"in","EnglishValue":"86.6","MetricUnit":"mm","MetricValue":"2200","Type":"text","SpecificationGroup":null,"SortOrder":"11"}
Sweeping Width - Angled (± 30 Degrees)

86.6 in 2200 mm
{"Name":"Sweeping Width - Angled (± 30 Degrees)","SpecificationId":null,"TextValue":"Direct Drive","EnglishUnit":"in","EnglishValue":"86.6","MetricUnit":"mm","MetricValue":"2200","Type":"measurement","SpecificationGroup":null,"SortOrder":"12"}
Overall Width - Angled (± 30 Degrees)

94.5 in 2400 mm
{"Name":"Overall Width - Angled (± 30 Degrees)","SpecificationId":null,"TextValue":"Requires Hook Group","EnglishUnit":"in","EnglishValue":"94.5","MetricUnit":"mm","MetricValue":"2400","Type":"measurement","SpecificationGroup":null,"SortOrder":"13"}
Drive Method

Direct Drive
{"Name":"Drive Method","SpecificationId":null,"TextValue":"Direct Drive","EnglishUnit":"in","EnglishValue":"98.4","MetricUnit":"mm","MetricValue":"2500","Type":"text","SpecificationGroup":null,"SortOrder":"14"}
Interface Type

Requires Hook Group
{"Name":"Interface Type","SpecificationId":null,"TextValue":"Requires Hook Group","EnglishUnit":"in","EnglishValue":"94.5","MetricUnit":"mm","MetricValue":"2400","Type":"text","SpecificationGroup":null,"SortOrder":"15"}
Voltage

12V
{"Name":"Voltage","SpecificationId":null,"TextValue":"12V","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"18"}
Voltage Type

12V
{"Name":"Voltage Type","SpecificationId":null,"TextValue":"12V","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"18"}

Benefits

Application

Ideal for clearing parking lots, industrial plants, mill yards, airport runways, streets, driveways and lanes.

Variable Sweeping Angle

Angles hydraulically or manually 30 degrees left or right; will also clean in straight position.

Unique Suspension

Unique suspension system eliminates the need for support wheels. Brush maintains constant ground pressure through a range of vertical motion from the initial setting.

Parking Supports

Parking supports provide stable and secure parking of the broom when not in use.

Re-designed Leveling Indicator

Leveling indicator allows operator to conveniently see the level of the broom from the cab during operation.

Protected Hydraulic Motors

Hydraulic motors are protected from dust and debris - yet easily accessible if needed.

Optional Water Sprinkler Kit

An optional water sprinkler kit is available which helps reduce the amount of airborne dust during sweeping operations.

Polypropylene and Wire Bristle Options

Cat® Angle Brooms come standard with a 50/50 mix of replaceable polypropylene and steel wire sections. Convoluted bristle sections can be converted to all wire or all poly for special applications.

Tool Mounted Operation and Maintenance Manual (OMM) Holder

Tool mounted and sealed from the elements, this holder includes all of the operation manuals and maintenance guides required for proper operation of the work tool.
