BR320

Get in touch

Cat® Brushcutters are used for clearing overgrowth from highway medians, utility easements and for initial land clearing for housing, parks and recreational areas. Cat® Industrial Brushcutters are designed for land management, utilities, site prep and maintenance work for brush, small trees, and dense vegetation.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Overall Width

80 in 2032 mm
{"Name":"Overall Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"80","MetricUnit":"mm","MetricValue":"2032","Type":"measurement","SpecificationGroup":null,"SortOrder":"1"}
Cutting Width

78 in 1981 mm
{"Name":"Cutting Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"78","MetricUnit":"mm","MetricValue":"1981","Type":"measurement","SpecificationGroup":null,"SortOrder":"2"}
Maximum Cutting Diameter

3 in 76 mm
{"Name":"Maximum Cutting Diameter","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"3","MetricUnit":"mm","MetricValue":"76","Type":"measurement","SpecificationGroup":null,"SortOrder":"3"}
Required Hydraulics

High Flow XPS
{"Name":"Required Hydraulics","SpecificationId":null,"TextValue":"High Flow XPS","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"4"}
Overall Length

91 in 2311 mm
{"Name":"Overall Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"91","MetricUnit":"mm","MetricValue":"2311","Type":"measurement","SpecificationGroup":null,"SortOrder":"5"}
Overall Height

20.9 in 531 mm
{"Name":"Overall Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"20.9","MetricUnit":"mm","MetricValue":"531","Type":"measurement","SpecificationGroup":null,"SortOrder":"6"}
Weight

1179.5 lb 535 kg
{"Name":"Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"1179.5","MetricUnit":"kg","MetricValue":"535","Type":"measurement","SpecificationGroup":null,"SortOrder":"7"}
Optimal Hydraulic Flow

76-130 L/min (20-34 gpm)
{"Name":"Optimal Hydraulic Flow","SpecificationId":null,"TextValue":"76-130 L/min (20-34 gpm)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"8"}
Optimal Hydraulic Pressure

150-280 bar (2176-4065 psi)
{"Name":"Optimal Hydraulic Pressure","SpecificationId":null,"TextValue":"150-280 bar (2176-4065 psi)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"9"}
Tip Speed (Depends On Flow)

4,176-6,032 mpm (13,700-19,790 fpm)
{"Name":"Tip Speed (Depends On Flow)","SpecificationId":null,"TextValue":"4,176-6,032 mpm (13,700-19,790 fpm)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"10"}
Motor Displacement

12 in³/rev 196 cm³/rev
{"Name":"Motor Displacement","SpecificationId":null,"TextValue":null,"EnglishUnit":"in³/rev","EnglishValue":"12","MetricUnit":"cm³/rev","MetricValue":"196","Type":"measurement","SpecificationGroup":null,"SortOrder":"11"}
Drive Shaft Torque

297-554 N·m (219-409 lb/ft)
{"Name":"Drive Shaft Torque","SpecificationId":null,"TextValue":"297-554 N·m (219-409 lb/ft)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"13"}

Benefits

Application

Cat® Brushcutters are used for clearing overgrowth from highway medians, utility easements and for initial land clearing for housing, parks and recreational areas.

Blades and Blade Carriers

High strength blades deliver high cutting action, durability and also mulch overgrowth. Fully balanced blade carrier prevents unnecessary vibration. Tapered blade carrier allows cutter to ride up over stumps and rocks.

Long Life Motor and Gears

Long life motor deliver years of high-speed blade performance. Machined and heat-treated gears in sealed gearbox provide reliable, durable transfer of torque from motor to blade carrier.

Motor Protection Guard

Motor protection guard shields motor and gear box from debris. Removing a set of bolts allows this hinged guard to be moved away for easy access to motor and gearbox.

Galvanized Coil Chains

Galvanized coil chains (7.9 mm [5/16 in] proof) provide debris guarding in the front and rear areas to restrict flying debris and material.

Heavy-Duty Skids

Heavy-duty skids allow easy movement of the brushcutter through uneven terrain while maintaining stability of the work tool and machine.
