B8 Side Mount

Get in touch

Cat® Hammers for Skid Steer Loaders, Compact Track Loaders, Mini Excavators and Backhoe Loaders are high performance breakers, designed for maximum performance on demolition, construction, and road work.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Operating Weight - With Tool

802.5 lb 364 kg
{"Name":"Operating Weight - With Tool","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"802.5","MetricUnit":"kg","MetricValue":"364","Type":"measurement","SpecificationGroup":null,"SortOrder":"1"}
Energy Class

848.2 ft·lbf 1150 J
{"Name":"Energy Class","SpecificationId":null,"TextValue":null,"EnglishUnit":"ft·lbf","EnglishValue":"848.2","MetricUnit":"J","MetricValue":"1150","Type":"measurement","SpecificationGroup":null,"SortOrder":"2"}
Machine Class

415-444 Backhoe Loaders
{"Name":"Machine Class","SpecificationId":null,"TextValue":"415-444 Backhoe Loaders","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"3"}
Tool Shaft Diameter

3 in 75 mm
{"Name":"Tool Shaft Diameter","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"3","MetricUnit":"mm","MetricValue":"75","Type":"measurement","SpecificationGroup":null,"SortOrder":"4"}
Impact Frequency

400-800 bpm
{"Name":"Impact Frequency","SpecificationId":null,"TextValue":"400-800 bpm","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"5"}
Minimum Operating Pressure

1704.1 psi 11749 kPa
{"Name":"Minimum Operating Pressure","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"1704.1","MetricUnit":"kPa","MetricValue":"11749","Type":"measurement","SpecificationGroup":null,"SortOrder":"6"}
Minimum Carrier Weight

13227.7 lb 6000 kg
{"Name":"Minimum Carrier Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"13227.7","MetricUnit":"kg","MetricValue":"6000","Type":"measurement","SpecificationGroup":null,"SortOrder":"7"}
Optimal Hydraulic Flow

50-90 lpm (13.2-23.8 gpm)
{"Name":"Optimal Hydraulic Flow","SpecificationId":null,"TextValue":"50-90 lpm (13.2-23.8 gpm)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"8"}
Overall Width

15.2 in 385 mm
{"Name":"Overall Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"15.2","MetricUnit":"mm","MetricValue":"385","Type":"measurement","SpecificationGroup":null,"SortOrder":"9"}
Overall Length

27.5 in 698 mm
{"Name":"Overall Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"27.5","MetricUnit":"mm","MetricValue":"698","Type":"measurement","SpecificationGroup":null,"SortOrder":"10"}
Overall Height

59.6 in 1514 mm
{"Name":"Overall Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"59.6","MetricUnit":"mm","MetricValue":"1514","Type":"measurement","SpecificationGroup":null,"SortOrder":"11"}
Height - Without Tool

43.5 in 1106 mm
{"Name":"Height - Without Tool","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"43.5","MetricUnit":"mm","MetricValue":"1106","Type":"measurement","SpecificationGroup":null,"SortOrder":"12"}
Sound Level

133 dB
{"Name":"Sound Level","SpecificationId":null,"TextValue":"133 dB","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"13"}
Mounting Bracket Size

Pin On
{"Name":"Mounting Bracket Size","SpecificationId":null,"TextValue":"Pin On","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"14"}

Benefits

Application

Cat® B Hammers are suitable for use in a wide range of construction and light demolition applications - such as breaking concrete sidewalks and driveways, pavement, roads, masonry, site prep and landscaping, and breaking frozen ground for utility repairs.

Unique Housing - Optimized to fit Caterpillar Backhoe Loaders

The robust housing incorporates two mounting configurations, for either pin-on (red arrow) or pin grabber quick coupler (green arrow) machine installation.

Integral Strain Relief Hose Routing Specifically Designed for Backhoe Loaders

Includes integral strain relief for the jumper lines. The clean lines routing, Caterpillar Toughguard hose material, and abrasion sleeve protect against damage during demolition applications or when tucked in roading position.

Pin On/Side Mount Style

Pin On/Side Mount style hammers provide more flexibility and are better suited for highway or construction breaking jobs. The reduced number of bolted joints also provides a more robust frame that increases hammer longevity.

Slip Fit Bushings

Slip fit bushings are field replaceable and easy to maintain due to one locking pin, extending wear life and reducing owning and operating costs. Upper bushing rotates 360°, lower bushing has two positions and can be rotated 90°.

Gas Fired Design

Gas fired design delivers consistently high production over time making the breaker reliable in applications such as concrete, asphalt, rock and light trenching.

Everything Is In The Box

The hammer is delivered ‘dirt-ready,’ and includes mounting pins, preassembled jumper lines, transverse chisel & conical style hammer tools, and tool box w/charging kit & service parts. Quick disconnects must be ordered separately.
