CB1.8
Tandem Vibratory Rollers
CB1.8
Tandem Vibratory Rollers
Book a Demo
Explore my deals
-
Overall Length80 in 2040 mm
-
Overall Width44 in 1112 mm
-
Drum Diameter22.5 in 575 mm
-
Drum Width39 in 1000 mm
-
Maximum Machine Height94.5 in 2400 mm
-
Engine Power (1)24.7 hp 18.7 kW
-
Engine ModelCat C1.1
-
Standard Compaction Width39 in 1000 mm
-
Curb Clearance16 in 403 mm
-
Ground Clearance10 in 251 mm
-
Travel Speed - Maximum5.3 mile/h 8.6 km/h
-
Static Linear Load63 lb/in 9.1 kg/cm
-
Turning Radius - Inside Drum Edge75 in 1900 mm
-
Fuel Tank Capacity7.9 gal (US) 30 l
-
Water Spray Tank Capacity38 gal (US) 145 l
-
Frequency3420 V/m 57 Hz
-
Nominal Amplitude - High0.018 in 0.47 mm
-
Centrifugal Force per Drum - Maximum3057 lb 13.6 kN
-
Operating Weight3825 lb 1735 kg
Simple Operation
- Ergonomic operating environment with vandal protection
- Spacious seating and easy access due to logically placed handles and lower platform height
- Simple operation with mechanical propel and speed control levers
Efficient Performance
- Compact size for excellent maneuverability in tight spaces
- Excellent drum-edge visibility enhances control for better coverage and compaction results
- Industry-leading compaction force delivers outstanding results
- Industry-leading water tank capacity of 145 L (38 gal) sized for less fills throughout the day
- Single-Point Lift for trench work and alternative transport options
Optimized Power
- Powerful Cat® C1.1 engine; single source supplier for parts, service, and support
- Cooling system capability of up to 49º C (120º F) for good performance in harsh environments
- Quickly move around the job site with a fast travel speed of 8.6 kph (5.3 mph) for good mobility
Reliable and Easy to Maintain
- 3 year/3000 hour vibratory drum service interval
- Reliable triple filtration design for the water spray system
- Easy access to engine service points
- Robust hitch design easily supports single lift point option
- Remote monitoring available with Product Link™ option
Operator Environment
Compaction System
Powertrain
Technology
Electrical
Other
