279D3

Cat® Compact Track Loaders feature a steel embedded track and steel undercarriage components for maximum life in applications where maintenance, operator technique and underfoot conditions may not be ideally suited for a Multi Terrain Loader or Skid Steer Loader.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Air Conditioning System (if equipped)

Air Conditioning

The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.0 kg of refrigerant which has a CO2 equivalent of 1.430 metric tonnes.
{"Name":"Air Conditioning","SpecificationId":null,"TextValue":"The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.0 kg of refrigerant which has a CO2 equivalent of 1.430 metric tonnes.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Air Conditioning System (if equipped)","SortOrder":"99"}

Cab

ROPS

ISO 3471:2008
{"Name":"ROPS","SpecificationId":null,"TextValue":"ISO 3471:2008","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Cab","SortOrder":"59"}
FOPS

ISO 3449:2005 Level I
{"Name":"FOPS","SpecificationId":null,"TextValue":"ISO 3449:2005 Level I","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Cab","SortOrder":"60"}

Dimensions

Length - Track on Ground

64.2 in 1630 mm
{"Name":"Length - Track on Ground","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"64.2","MetricUnit":"mm","MetricValue":"1630","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"33"}
Overall Length - Track

83.8 in 2129 mm
{"Name":"Overall Length - Track","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"83.8","MetricUnit":"mm","MetricValue":"2129","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"34"}
Height - Top of Cab

83.2 in 2113 mm
{"Name":"Height - Top of Cab","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"83.2","MetricUnit":"mm","MetricValue":"2113","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"37"}
Ground Clearance

8.9 in 226 mm
{"Name":"Ground Clearance","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"8.9","MetricUnit":"mm","MetricValue":"226","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"44"}
Departure Angle

32°
{"Name":"Departure Angle","SpecificationId":null,"TextValue":"32°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"45"}
Maximum Dump Angle

39°
{"Name":"Maximum Dump Angle","SpecificationId":null,"TextValue":"39°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"46"}
Bucket Pin Height - Carry Position

7.8 in 198 mm
{"Name":"Bucket Pin Height - Carry Position","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"7.8","MetricUnit":"mm","MetricValue":"198","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Turning Radius from Center - Machine Rear

70.7 in 1796 mm
{"Name":"Turning Radius from Center - Machine Rear","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"70.7","MetricUnit":"mm","MetricValue":"1796","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Turning Radius from Center - Coupler

55.5 in 1410 mm
{"Name":"Turning Radius from Center - Coupler","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"55.5","MetricUnit":"mm","MetricValue":"1410","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Maximum Overall Height

159.5 in 4051 mm
{"Name":"Maximum Overall Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"159.5","MetricUnit":"mm","MetricValue":"4051","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Maximum Reach - With Arms Parallel to Ground

54 in 1373 mm
{"Name":"Maximum Reach - With Arms Parallel to Ground","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"54","MetricUnit":"mm","MetricValue":"1373","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Turning Radius from Center - Bucket

88.8 in 2256 mm
{"Name":"Turning Radius from Center - Bucket","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"88.8","MetricUnit":"mm","MetricValue":"2256","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Bucket Pin Height - Maximum Lift

124.9 in 3173 mm
{"Name":"Bucket Pin Height - Maximum Lift","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"124.9","MetricUnit":"mm","MetricValue":"3173","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Length - With Bucket on Ground

146.2 in 3714 mm
{"Name":"Length - With Bucket on Ground","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"146.2","MetricUnit":"mm","MetricValue":"3714","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Length - Without Bucket

117.9 in 2995 mm
{"Name":"Length - Without Bucket","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"117.9","MetricUnit":"mm","MetricValue":"2995","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Reach - Maximum Lift/Dump

22.6 in 575 mm
{"Name":"Reach - Maximum Lift/Dump","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"22.6","MetricUnit":"mm","MetricValue":"575","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Note

Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, two speed, OROPS, 2036 mm (80 in) low profile bucket, 450 mm (17.7 in) tracks, dual flange front idler/single flange rear idler, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).
{"Name":"Note","SpecificationId":null,"TextValue":"Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, two speed, OROPS, 2036 mm (80 in) low profile bucket, 450 mm (17.7 in) tracks, dual flange front idler/single flange rear idler, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"99"}
Clearance at Maximum Lift and Dump

97.8 in 2485 mm
{"Name":"Clearance at Maximum Lift and Dump","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"97.8","MetricUnit":"mm","MetricValue":"2485","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Vehicle Width (450 mm/17.7 in tracks)

78 in 1981 mm
{"Name":"Vehicle Width (450 mm/17.7 in tracks)","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"78","MetricUnit":"mm","MetricValue":"1981","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Rack Back Angle - Maximum Height

84°
{"Name":"Rack Back Angle - Maximum Height","SpecificationId":null,"TextValue":"84°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"99"}

Engine

Gross Power - SAE J1995

74.3 hp 55.4 kW
{"Name":"Gross Power - SAE J1995","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"74.3","MetricUnit":"kW","MetricValue":"55.4","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"1"}
Net Power - SAE 1349

72.9 hp 54.4 kW
{"Name":"Net Power - SAE 1349","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"72.9","MetricUnit":"kW","MetricValue":"54.4","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"10"}
Displacement

203 in³ 3.3 l
{"Name":"Displacement","SpecificationId":null,"TextValue":null,"EnglishUnit":"in³","EnglishValue":"203","MetricUnit":"l","MetricValue":"3.3","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"11"}
Bore

3.7 in 94 mm
{"Name":"Bore","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"3.7","MetricUnit":"mm","MetricValue":"94","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"12"}
Stroke

4.7 in 120 mm
{"Name":"Stroke","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"4.7","MetricUnit":"mm","MetricValue":"120","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"13"}
Peak Torque - 1,500 rpm - SAE J1995

195 ft·lbf 265 N·m
{"Name":"Peak Torque - 1,500 rpm - SAE J1995","SpecificationId":null,"TextValue":null,"EnglishUnit":"ft·lbf","EnglishValue":"195","MetricUnit":"N·m","MetricValue":"265","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Net Power

72.9 hp 54.4 kW
{"Name":"Net Power","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"72.9","MetricUnit":"kW","MetricValue":"54.4","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Note

Net power advertised is the power available at the flywheel when the engine is equipped with alternator, air cleaner, muffler/aftertreatment and cooling fan.
{"Name":"Note","SpecificationId":null,"TextValue":"Net power advertised is the power available at the flywheel when the engine is equipped with alternator, air cleaner, muffler/aftertreatment and cooling fan.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}
Gross Power

74.3 hp 55.4 kW
{"Name":"Gross Power","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"74.3","MetricUnit":"kW","MetricValue":"55.4","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Engine Model

Cat C3.3B DIT (turbo)
{"Name":"Engine Model","SpecificationId":null,"TextValue":"Cat C3.3B DIT (turbo)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}
Net Power - ISO 9249

73.7 hp 54.9 kW
{"Name":"Net Power - ISO 9249","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"73.7","MetricUnit":"kW","MetricValue":"54.9","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}

Hydraulic System

Hydraulic Flow - Standard - Loader Hydraulic Pressure

3335 psi 23000 kPa
{"Name":"Hydraulic Flow - Standard - Loader Hydraulic Pressure","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"3335","MetricUnit":"kPa","MetricValue":"23000","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Flow

32 gal/min 121 l/min
{"Name":"Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Flow","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal/min","EnglishValue":"32","MetricUnit":"l/min","MetricValue":"121","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - Standard - Loader Hydraulic Flow

23 psi 86 kPa
{"Name":"Hydraulic Flow - Standard - Loader Hydraulic Flow","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"23","MetricUnit":"kPa","MetricValue":"86","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - Standard - Hydraulic Power (Calculated)

44 hp 33 kW
{"Name":"Hydraulic Flow - Standard - Hydraulic Power (Calculated)","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"44","MetricUnit":"kW","MetricValue":"33","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Pressure

4061 hp 28000 kW
{"Name":"Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Pressure","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"4061","MetricUnit":"kW","MetricValue":"28000","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - High Flow XPS - Hydraulic Power (Calculated)

76 hp 57 kPa
{"Name":"Hydraulic Flow - High Flow XPS - Hydraulic Power (Calculated)","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"76","MetricUnit":"kPa","MetricValue":"57","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}

Noise Level

Note (2)

**The declared dynamic operator sound pressure levels per ISO 6396:2008. The measurements were conducted with the cab doors and windows closed and at 70% of the maximum engine cooling fan speed. The sound level may vary at different engine cooling fan speeds.
{"Name":"Note (2)","SpecificationId":null,"TextValue":"**The declared dynamic operator sound pressure levels per ISO 6396:2008. The measurements were conducted with the cab doors and windows closed and at 70% of the maximum engine cooling fan speed. The sound level may vary at different engine cooling fan speeds.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Noise Level","SortOrder":"99"}
Outside Cab***

103 dB(A) 103 dB(A)
{"Name":"Outside Cab***","SpecificationId":null,"TextValue":null,"EnglishUnit":"dB(A)","EnglishValue":"103","MetricUnit":"dB(A)","MetricValue":"103","Type":"measurement","SpecificationGroup":"Noise Level","SortOrder":"99"}
Note (3)

***The labeled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC.
{"Name":"Note (3)","SpecificationId":null,"TextValue":"***The labeled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Noise Level","SortOrder":"99"}
Inside Cab**

83 dB(A) 83 dB(A)
{"Name":"Inside Cab**","SpecificationId":null,"TextValue":null,"EnglishUnit":"dB(A)","EnglishValue":"83","MetricUnit":"dB(A)","MetricValue":"83","Type":"measurement","SpecificationGroup":"Noise Level","SortOrder":"99"}
Note (1)

Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe.
{"Name":"Note (1)","SpecificationId":null,"TextValue":"Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Noise Level","SortOrder":"99"}

Operating Specifications

Rated Operating Capacities - 35% Tipping Load

2220 lb 1010 kg
{"Name":"Rated Operating Capacities - 35% Tipping Load","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"2220","MetricUnit":"kg","MetricValue":"1010","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"2"}
Tipping Load

6345 lb 2885 kg
{"Name":"Tipping Load","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"6345","MetricUnit":"kg","MetricValue":"2885","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"21"}
Breakout Force - Tilt Cylinder

7285 lb 3304 kg
{"Name":"Breakout Force - Tilt Cylinder","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"7285","MetricUnit":"kg","MetricValue":"3304","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"25"}
Rated Operating Capacities - 50% Tipping Load

3170 lb 1445 kg
{"Name":"Rated Operating Capacities - 50% Tipping Load","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"3170","MetricUnit":"kg","MetricValue":"1445","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"99"}
Ground Contact Area - With 450 mm/17.7 in Track

2272 in² 1.47 m²
{"Name":"Ground Contact Area - With 450 mm/17.7 in Track","SpecificationId":null,"TextValue":null,"EnglishUnit":"in²","EnglishValue":"2272","MetricUnit":"m²","MetricValue":"1.47","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"99"}
Note

Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, two speed, OROPS, 2036 mm (80 in) low profile bucket, 450 mm (17.7 in) tracks, dual flange front idler/single flange rear idler, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).
{"Name":"Note","SpecificationId":null,"TextValue":"Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, two speed, OROPS, 2036 mm (80 in) low profile bucket, 450 mm (17.7 in) tracks, dual flange front idler/single flange rear idler, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Operating Specifications","SortOrder":"99"}
Rated Operating Capacity with Optional Counterweight

3390 lb 1540 kg
{"Name":"Rated Operating Capacity with Optional Counterweight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"3390","MetricUnit":"kg","MetricValue":"1540","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"99"}
Ground Pressure - With 450 mm/17.7 in Track

4.4 psi 30.4 kPa
{"Name":"Ground Pressure - With 450 mm/17.7 in Track","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"4.4","MetricUnit":"kPa","MetricValue":"30.4","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"99"}

Power Train

Travel Speed - Forward or Reverse - Two Speed

8.3 mile/h 13.3 km/h
{"Name":"Travel Speed - Forward or Reverse - Two Speed","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"8.3","MetricUnit":"km/h","MetricValue":"13.3","Type":"measurement","SpecificationGroup":"Power Train","SortOrder":"99"}
Travel Speed - Forward or Reverse - One Speed

4.5 mile/h 7.2 km/h
{"Name":"Travel Speed - Forward or Reverse - One Speed","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"4.5","MetricUnit":"km/h","MetricValue":"7.2","Type":"measurement","SpecificationGroup":"Power Train","SortOrder":"99"}

Service Refill Capacities

Hydraulic System

13.7 gal (US) 52 l
{"Name":"Hydraulic System","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"13.7","MetricUnit":"l","MetricValue":"52","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Hydraulic Tank

10.3 gal (US) 39 l
{"Name":"Hydraulic Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"10.3","MetricUnit":"l","MetricValue":"39","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Fuel Tank

27.7 gal (US) 105 l
{"Name":"Fuel Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"27.7","MetricUnit":"l","MetricValue":"105","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Engine Crankcase

3 gal (US) 11 l
{"Name":"Engine Crankcase","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"3","MetricUnit":"l","MetricValue":"11","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Cooling System

3.7 gal (US) 14 l
{"Name":"Cooling System","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"3.7","MetricUnit":"l","MetricValue":"14","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}

Weights

Operating Weight

10095 lb 4579 kg
{"Name":"Operating Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"10095","MetricUnit":"kg","MetricValue":"4579","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"3"}
Note

Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, two speed, OROPS, 2036 mm (80 in) low profile bucket, 450 mm (17.7 in) tracks, dual flange front idler/single flange rear idler, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).
{"Name":"Note","SpecificationId":null,"TextValue":"Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, two speed, OROPS, 2036 mm (80 in) low profile bucket, 450 mm (17.7 in) tracks, dual flange front idler/single flange rear idler, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Weights","SortOrder":"16"}

Benefits

Quiet and Comfortable

The industry leading sealed and pressurized cab option provides the operator with a cleaner and quieter operating environment with excellent work tool visibility. Continuing the industry leading trend, the D3 Series also includes as standard, seat mounted adjustable joystick controls for operator comfort.

Maximum Performance

High performance power train provides maximum performance and production capability through the Electronic Torque Management system, standard two speed travel and an electronic hand/foot throttle with decel pedal capability.

Making Your Job Easier

Cat® “Intelligent Leveling” system provides industry leading technology, integration, and available features such as dual direction self level, work tool return to dig, and work tool positioner.

A Smooth Ride

A standard, fully independent torsion axle suspension combined with the optional Speed Sensitive Ride Control system improves operation on rough terrain, enabling better load retention, increased productivity and greater operator comfort.

Optimized Machine Capability

Maximize machine capability and control with the available Advanced Display, providing on-screen adjustments for implement response, hystat response and creep control. Also features multi-language functionality with customizable layouts, security system and rearview camera.

Sustainability

The Cat® C3.3B engine meets U.S. EPA Tier 4 Final and EU Stage V emission standards.
Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 7% biodiesel FAME (fatty acid methyl ester). Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details.
Cat® Extended Life Coolant and long-life HYDO Advanced hydraulic fluids not only reduce downtime but help decrease the amount of fluid and filters that are replaced over the life of the machine.
Boost productivity with Cat technologies like work tool positioner, return to dig, and Cat Smart Attachments.
Save fuel and reduce your greenhouse gas emissions with efficiency features such as foot throttle pedal and cooling system demand fan.

Equipment Info

ELECTRICAL

12 volt Electrical System

OPERATOR ENVIRONMENT

Advanced Display with Rearview Camera: Full Color, 127 mm (5 in) LCD screen; Advanced Multi-operator Security System; On-screen Adjustments for Implement Response, Hystat Response, and Creep Control

POWER TRAIN

Cat C3.3B, Turbo Diesel Engine, Meeting Tier 4 Final and Stage V Emission Standards

OTHER

Engine Enclosure, Lockable

MANDATORY EQUIPMENT

Hydraulics, Standard or High Flow XPS
