260 | Toromont Cat

Built for tough work, the Cat® Skid Steer Loaders incorporate big iron features. These machines deliver reliability, durability, and efficient operation, even in the toughest working conditions.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Air Conditioning System (if equipped)

Air Conditioning

The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.85 kg of refrigerant which has a CO2 equivalent of 1.216 metric tonnes.
{"Name":"Air Conditioning","SpecificationId":null,"TextValue":"The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.85 kg of refrigerant which has a CO2 equivalent of 1.216 metric tonnes.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Air Conditioning System (if equipped)","SortOrder":"99"}

Cab

ROPS

ISO 3471:2008
{"Name":"ROPS","SpecificationId":null,"TextValue":"ISO 3471:2008","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Cab","SortOrder":"45"}
FOPS

ISO 3449:2005 Level I
{"Name":"FOPS","SpecificationId":null,"TextValue":"ISO 3449:2005 Level I","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Cab","SortOrder":"46"}
FOPS Level II

ISO 3449:2005 (Optional)
{"Name":"FOPS Level II","SpecificationId":null,"TextValue":"ISO 3449:2005 (Optional)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Cab","SortOrder":"47"}

Dimensions

Wheel Base

49.2 in 1249 mm
{"Name":"Wheel Base","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"49.2","MetricUnit":"mm","MetricValue":"1249","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"19"}
Height - Top of Cab

81.9 in 2100 mm
{"Name":"Height - Top of Cab","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"81.9","MetricUnit":"mm","MetricValue":"2100","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"22"}
Vehicle Width over Tires

66.5 in 1690 mm
{"Name":"Vehicle Width over Tires","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"66.5","MetricUnit":"mm","MetricValue":"1690","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"23"}
Ground Clearance

7.9 in 201 mm
{"Name":"Ground Clearance","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"7.9","MetricUnit":"mm","MetricValue":"201","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"29"}
Departure Angle

23°
{"Name":"Departure Angle","SpecificationId":null,"TextValue":"23°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"30"}
Maximum Dump Angle

46°
{"Name":"Maximum Dump Angle","SpecificationId":null,"TextValue":"46°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"32"}
Bucket Pin Height - Maximum Lift

132.5 in 3365 mm
{"Name":"Bucket Pin Height - Maximum Lift","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"132.5","MetricUnit":"mm","MetricValue":"3365","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Bucket Pin Height - Carry Position

8 in 203 mm
{"Name":"Bucket Pin Height - Carry Position","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"8","MetricUnit":"mm","MetricValue":"203","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Clearance at Maximum Lift and Dump

96.2 in 2646 mm
{"Name":"Clearance at Maximum Lift and Dump","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"96.2","MetricUnit":"mm","MetricValue":"2646","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Maximum Overall Height

155.8 in 4160 mm
{"Name":"Maximum Overall Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"155.8","MetricUnit":"mm","MetricValue":"4160","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Length - With Bucket on Ground

135 in 3575 mm
{"Name":"Length - With Bucket on Ground","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"135","MetricUnit":"mm","MetricValue":"3575","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Note

Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, one speed, OROPS (Open Roll Over Protection System), 1730 mm (68 in) low profile bucket, Cat 12 × 16.5 tires, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).
{"Name":"Note","SpecificationId":null,"TextValue":"Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, one speed, OROPS (Open Roll Over Protection System), 1730 mm (68 in) low profile bucket, Cat 12 × 16.5 tires, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"99"}
Turning Radius from Center - Bucket

82.7 in 2102 mm
{"Name":"Turning Radius from Center - Bucket","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"82.7","MetricUnit":"mm","MetricValue":"2102","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Bucket Pin Reach - Maximum Lift

12.6 in 320 mm
{"Name":"Bucket Pin Reach - Maximum Lift","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"12.6","MetricUnit":"mm","MetricValue":"320","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Maximum Reach - With Arms Parallel to Ground

44.1 in 1120 mm
{"Name":"Maximum Reach - With Arms Parallel to Ground","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"44.1","MetricUnit":"mm","MetricValue":"1120","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Length - Without Bucket

116.4 in 2956 mm
{"Name":"Length - Without Bucket","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"116.4","MetricUnit":"mm","MetricValue":"2956","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Reach - Maximum Lift/Dump

21.7 in 552 mm
{"Name":"Reach - Maximum Lift/Dump","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"21.7","MetricUnit":"mm","MetricValue":"552","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Turning Radius from Center - Coupler

53.8 in 1367 mm
{"Name":"Turning Radius from Center - Coupler","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"53.8","MetricUnit":"mm","MetricValue":"1367","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Turning Radius from Center - Machine Rear

71.8 in 1823 mm
{"Name":"Turning Radius from Center - Machine Rear","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"71.8","MetricUnit":"mm","MetricValue":"1823","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"99"}
Roll Back Angle

28°
{"Name":"Roll Back Angle","SpecificationId":null,"TextValue":"28°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"99"}
Rack Back Angle - Maximum Height

97°
{"Name":"Rack Back Angle - Maximum Height","SpecificationId":null,"TextValue":"97°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Dimensions","SortOrder":"99"}

Engine

Gross Power - SAE J1995:2014

74 hp 55 kW
{"Name":"Gross Power - SAE J1995:2014","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"74","MetricUnit":"kW","MetricValue":"55","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"1"}
Net Power - SAE 1349

74 hp 55 kW
{"Name":"Net Power - SAE 1349","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"74","MetricUnit":"kW","MetricValue":"55","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"10"}
Displacement

171 in³ 2.8 l
{"Name":"Displacement","SpecificationId":null,"TextValue":null,"EnglishUnit":"in³","EnglishValue":"171","MetricUnit":"l","MetricValue":"2.8","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"11"}
Stroke

4.3 in 110 mm
{"Name":"Stroke","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"4.3","MetricUnit":"mm","MetricValue":"110","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"12"}
Bore

3.5 in 90 mm
{"Name":"Bore","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"3.5","MetricUnit":"mm","MetricValue":"90","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"13"}
Note

Advertised power is tested per the specified standard in effect at the time of manufacture. Net power advertised is the power available at the flywheel when the engine is equipped with fan at minimum speed, air intake system, exhaust system, and alternator.
{"Name":"Note","SpecificationId":null,"TextValue":"Advertised power is tested per the specified standard in effect at the time of manufacture. Net power advertised is the power available at the flywheel when the engine is equipped with fan at minimum speed, air intake system, exhaust system, and alternator.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}
Peak Torque - 1,600 rpm - SAE J1995

221 lb/ft 300 N·m
{"Name":"Peak Torque - 1,600 rpm - SAE J1995","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb/ft","EnglishValue":"221","MetricUnit":"N·m","MetricValue":"300","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Net Power - ISO 9249

73 hp 55 kW
{"Name":"Net Power - ISO 9249","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"73","MetricUnit":"kW","MetricValue":"55","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Engine Model

Cat C2.8T (turbo)
{"Name":"Engine Model","SpecificationId":null,"TextValue":"Cat C2.8T (turbo)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}

Hydraulic System

Hydraulic Flow - Standard - Loader Hydraulic Pressure

3335 psi 24130 kPa
{"Name":"Hydraulic Flow - Standard - Loader Hydraulic Pressure","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"3335","MetricUnit":"kPa","MetricValue":"24130","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - High Flow - Hydraulic Power (Calculated)

58 hp 45.4 kW
{"Name":"Hydraulic Flow - High Flow - Hydraulic Power (Calculated)","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"58","MetricUnit":"kW","MetricValue":"45.4","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Flow

34 gpm 129 L/min
{"Name":"Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Flow","SpecificationId":null,"TextValue":null,"EnglishUnit":"gpm","EnglishValue":"34","MetricUnit":"L/min","MetricValue":"129","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - Standard - Loader Hydraulic Flow

20 gpm 86 L/min
{"Name":"Hydraulic Flow - Standard - Loader Hydraulic Flow","SpecificationId":null,"TextValue":null,"EnglishUnit":"gpm","EnglishValue":"20","MetricUnit":"L/min","MetricValue":"86","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - High Flow - Maximum Loader Hydraulic Flow

30 gpm 113 L/min
{"Name":"Hydraulic Flow - High Flow - Maximum Loader Hydraulic Flow","SpecificationId":null,"TextValue":null,"EnglishUnit":"gpm","EnglishValue":"30","MetricUnit":"L/min","MetricValue":"113","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - High Flow - Maximum Loader Hydraulic Pressure

3500 psi 24130 kPa
{"Name":"Hydraulic Flow - High Flow - Maximum Loader Hydraulic Pressure","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"3500","MetricUnit":"kPa","MetricValue":"24130","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Pressure

4061 psi 28000 kPa
{"Name":"Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Pressure","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"4061","MetricUnit":"kPa","MetricValue":"28000","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - High Flow XPS - Hydraulic Power (Calculated)

80.7 hp 60.2 kW
{"Name":"Hydraulic Flow - High Flow XPS - Hydraulic Power (Calculated)","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"80.7","MetricUnit":"kW","MetricValue":"60.2","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Hydraulic Flow - Standard - Hydraulic Power (Calculated)

39 hp 34.6 kW
{"Name":"Hydraulic Flow - Standard - Hydraulic Power (Calculated)","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"39","MetricUnit":"kW","MetricValue":"34.6","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}

Noise Level

Note (1)

Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe.
{"Name":"Note (1)","SpecificationId":null,"TextValue":"Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Noise Level","SortOrder":"99"}
Note (3)

**The labeled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC.
{"Name":"Note (3)","SpecificationId":null,"TextValue":"**The labeled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Noise Level","SortOrder":"99"}
Inside Cab*

83 dB(A)
{"Name":"Inside Cab*","SpecificationId":null,"TextValue":"83 dB(A)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Noise Level","SortOrder":"99"}
Note (2)

*The declared dynamic operator sound pressure levels per ISO 6396:2008. The measurements were conducted with the cab doors and windows closed and at 70% of the maximum engine cooling fan speed. The sound level may vary at different engine cooling fan speeds.
{"Name":"Note (2)","SpecificationId":null,"TextValue":"*The declared dynamic operator sound pressure levels per ISO 6396:2008. The measurements were conducted with the cab doors and windows closed and at 70% of the maximum engine cooling fan speed. The sound level may vary at different engine cooling fan speeds.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Noise Level","SortOrder":"99"}
Outside Cab**

101 dB(A)
{"Name":"Outside Cab**","SpecificationId":null,"TextValue":"101 dB(A)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Noise Level","SortOrder":"99"}

Operating Specifications

Rated Operating Capacity

3160 lb 1434 kg
{"Name":"Rated Operating Capacity","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"3160","MetricUnit":"kg","MetricValue":"1434","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"2"}
Tipping Load

6321 lb 2867 kg
{"Name":"Tipping Load","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"6321","MetricUnit":"kg","MetricValue":"2867","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"15"}
Breakout Force - Tilt Cylinder

9372 lb 4251 kg
{"Name":"Breakout Force - Tilt Cylinder","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"9372","MetricUnit":"kg","MetricValue":"4251","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"16"}
Breakout Force - Lift Cylinder

5948 lb 3121 kg
{"Name":"Breakout Force - Lift Cylinder","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"5948","MetricUnit":"kg","MetricValue":"3121","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"99"}
Rated Operating Capacity with Optional Counterweight

3388 lb 1540 kg
{"Name":"Rated Operating Capacity with Optional Counterweight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"3388","MetricUnit":"kg","MetricValue":"1540","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"99"}
Note

Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, one speed, OROPS (Open Roll Over Protection System), 1730 mm (68 in) low profile bucket, Cat 12 × 16.5 tires, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).
{"Name":"Note","SpecificationId":null,"TextValue":"Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, one speed, OROPS (Open Roll Over Protection System), 1730 mm (68 in) low profile bucket, Cat 12 × 16.5 tires, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Operating Specifications","SortOrder":"99"}

Power Train

Travel Speed - Forward or Reverse - One Speed

7.7 mile/h 12.4 km/h
{"Name":"Travel Speed - Forward or Reverse - One Speed","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"7.7","MetricUnit":"km/h","MetricValue":"12.4","Type":"measurement","SpecificationGroup":"Power Train","SortOrder":"99"}
Travel Speed - Forward or Reverse - Two Speed Option

11.1 mile/h 17.9 km/h
{"Name":"Travel Speed - Forward or Reverse - Two Speed Option","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"11.1","MetricUnit":"km/h","MetricValue":"17.9","Type":"measurement","SpecificationGroup":"Power Train","SortOrder":"99"}

Service Refill Capacities

Chain Box - Each Side

2.4 gal (US) 9 l
{"Name":"Chain Box - Each Side","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"2.4","MetricUnit":"l","MetricValue":"9","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"51"}
Cooling System

3 gal (US) 11.5 l
{"Name":"Cooling System","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"3","MetricUnit":"l","MetricValue":"11.5","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"52"}
Engine Crankcase

2.1 gal (US) 8 l
{"Name":"Engine Crankcase","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"2.1","MetricUnit":"l","MetricValue":"8","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"53"}
Fuel Tank

31 gal (US) 117.5 l
{"Name":"Fuel Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"31","MetricUnit":"l","MetricValue":"117.5","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"54"}
Hydraulic System

9.7 gal (US) 36.8 l
{"Name":"Hydraulic System","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"9.7","MetricUnit":"l","MetricValue":"36.8","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"55"}
Hydraulic Tank

6.9 gal (US) 26 l
{"Name":"Hydraulic Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"6.9","MetricUnit":"l","MetricValue":"26","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"56"}

Sustainability

Recyclability

93%
{"Name":"Recyclability","SpecificationId":null,"TextValue":"93%","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Sustainability","SortOrder":"99"}

Weights

Operating Weight

8523 lb 3866 kg
{"Name":"Operating Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"8523","MetricUnit":"kg","MetricValue":"3866","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"3"}
Note

Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, one speed, OROPS (Open Roll Over Protection System), 1730 mm (68 in) low profile bucket, Cat 12 × 16.5 tires, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).
{"Name":"Note","SpecificationId":null,"TextValue":"Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, one speed, OROPS (Open Roll Over Protection System), 1730 mm (68 in) low profile bucket, Cat 12 × 16.5 tires, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Weights","SortOrder":"99"}

Benefits

High Performance Power Train

High performance power train provides maximum performance and production capability through the Electronic Torque Management system, optional two speed travel and an electronic hand/foot throttle with decel pedal capability.

Redesigned Operator Station

Redesigned operator station delivers a larger operating environment. Combined with additional seat travel, the 260 provides more space for operators of any size. The optional one-piece, sealed, and pressurized cab offers a clean and quiet workspace with excellent air distribution through optimally placed vents throughout the cab.

Ventilated and Heated High-Back Air Ride Seat

Available ventilated and heated high-back air ride seat and seat-mounted adjustable joystick controls deliver superior operator comfort.

Three Levels of Auxiliary Hydraulic Performance

Three levels of auxiliary hydraulic performance available, Standard Flow, High Flow, and High Flow XPS. Standard flow for attachments that require a base level of auxiliary flow and horsepower, High Flow boosts the auxiliary flow for applications that demand additional hydraulic flow for increased attachment performance, and the High Flow XPS hydraulic system provides maximum auxiliary hydraulic performance by delivering additional flow and additional pressure for the most demanding attachments and applications.

Electronically Controlled Cat C2.8T Engine

Electronically controlled Cat C2.8T engine meets U.S. EPA Tier 4 Final and EU Stage V emission standards while delivering maximum horsepower across a wide RPM range and providing high torque for increased working performance, no matter the application.

Ride Control

Speed sensitive ride control option improves operation on rough terrain, enabling better load retention, increased productivity, and greater operator comfort.

Advanced Touchscreen Monitor

The 20.3 cm (8-inch) Advanced Touchscreen Monitor offers cutting-edge functionality and control that includes an integrated radio, Bluetooth® connectivity, and multi-camera (side-view) option, and supports 32 different language choices.

Advanced Joysticks

The Advanced Joysticks provide unmatched control of machine functions and adjustments within the display without having to remove your hands from the controls. This includes on-joystick navigation of the Advanced Touchscreen Monitor, radio volume up/down/mute, creep activation, creep on/off, creep speed increment/decrement, one-button Smart Attachment control activation, and additional auxiliary control buttons that deliver single-button control of complex attachment functions.

Ground-Level Access

Ground-level access to all daily service and routine maintenance points helps reduce machine downtime for greater productivity.

Cat Attachments

The broad range of performance matched Cat Attachments makes the Cat Skid Steer Loader the most versatile machine on the job site.

Equipment Info

ELECTRICAL

Work Tool Electrical Harness

RADIO

Radio, none – for open canopy machines and countries not certified for Bluetooth® technology

PRODUCT LINK™

Product Link Basic series PL243

COOLING FAN

On-demand, variable speed hydraulic cooling fan

GUARDING AND SEALING PACKAGES

HD0 – base guarding and sealing (engine air inlet rain cap, front cab-toframe sealing, and hydraulic fill access door)

OPERATOR ENVIRONMENT

Full color LCD monitor: Creep speed control, Drive response adjustment, Implement response adjustment, Drive Power Priority adjustment, Language selection (×32), Multi-operator Anti-theft Security System and Monitoring, Maintenance schedule and reminders, Event and Diagnostic Code monitoring, Date /Time/Units/Brightness settings, and Smart Technology for use with Smart Attachments.

HYDRAULICS

Selectable control pattern – ISO or H

POWER TRAIN

Cat C2.8T turbocharged diesel engine, Meeting U.S. EPA Tier 4 Final and EU Stage V emission standards

OTHER

Auxiliary Hydraulics, Continuous Flow

MANDATORY EQUIPMENT

Auxiliary Hydraulics: Standard or High Flow XPS

PERFORMANCE PACKAGES

Performance Package HP1: Standard Flow Hydraulics

COMFORT PACKAGES

Open canopy: Cup Holder, Cell Phone Pocket, choice of vinyl seat (Mechanical Suspension, High Back/Heated/Air Ride Seat

TECHNOLOGY PACKAGES

T2 – T1 + Rear-view camera.
