Specifications

Air Conditioning System

Air Conditioning

The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas.
{"Name":"Air Conditioning","SpecificationId":null,"TextValue":"The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Air Conditioning System","SortOrder":"99"}

Blade Range

Circle Centershift - Right

28.7 in 728 mm
{"Name":"Circle Centershift - Right","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"28.7","MetricUnit":"mm","MetricValue":"728","Type":"measurement","SpecificationGroup":"Blade Range","SortOrder":"85"}
Circle Centershift - Left

27.4 in 695 mm
{"Name":"Circle Centershift - Left","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"27.4","MetricUnit":"mm","MetricValue":"695","Type":"measurement","SpecificationGroup":"Blade Range","SortOrder":"86"}
Moldboard Sideshift - Right

26 in 660 mm
{"Name":"Moldboard Sideshift - Right","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"26","MetricUnit":"mm","MetricValue":"660","Type":"measurement","SpecificationGroup":"Blade Range","SortOrder":"87"}
Moldboard Sideshift - Left

20.1 in 510 mm
{"Name":"Moldboard Sideshift - Left","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"20.1","MetricUnit":"mm","MetricValue":"510","Type":"measurement","SpecificationGroup":"Blade Range","SortOrder":"88"}
Maximum Blade Position Angle

90°
{"Name":"Maximum Blade Position Angle","SpecificationId":null,"TextValue":"90°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Blade Range","SortOrder":"89"}
Blade Tip Range - Forward

40°
{"Name":"Blade Tip Range - Forward","SpecificationId":null,"TextValue":"40°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Blade Range","SortOrder":"90"}
Blade Tip Range - Backward

5°
{"Name":"Blade Tip Range - Backward","SpecificationId":null,"TextValue":"5°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Blade Range","SortOrder":"91"}
Maximum Lift Above Ground

17.8 in 452 mm
{"Name":"Maximum Lift Above Ground","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"17.8","MetricUnit":"mm","MetricValue":"452","Type":"measurement","SpecificationGroup":"Blade Range","SortOrder":"94"}
Maximum Depth of Cut

29.5 in 750 mm
{"Name":"Maximum Depth of Cut","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"29.5","MetricUnit":"mm","MetricValue":"750","Type":"measurement","SpecificationGroup":"Blade Range","SortOrder":"95"}
Maximum Shoulder Reach Outside of Tires - Left

82.3 in 2090 mm
{"Name":"Maximum Shoulder Reach Outside of Tires - Left","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"82.3","MetricUnit":"mm","MetricValue":"2090","Type":"measurement","SpecificationGroup":"Blade Range","SortOrder":"99"}
Maximum Shoulder Reach Outside of Tires - Right

89.7 in 2278 mm
{"Name":"Maximum Shoulder Reach Outside of Tires - Right","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"89.7","MetricUnit":"mm","MetricValue":"2278","Type":"measurement","SpecificationGroup":"Blade Range","SortOrder":"99"}

Dimensions

Height - Top of Cab

130 in 3308 mm
{"Name":"Height - Top of Cab","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"130","MetricUnit":"mm","MetricValue":"3308","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"145"}
Length - Counterweight to Ripper

399 in 10136 mm
{"Name":"Length - Counterweight to Ripper","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"399","MetricUnit":"mm","MetricValue":"10136","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"148"}
Width - Outside Front Tires

98.9 in 2511 mm
{"Name":"Width - Outside Front Tires","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"98.9","MetricUnit":"mm","MetricValue":"2511","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"149"}
Length - Front Axle to Mid Tandem

241 in 6123 mm
{"Name":"Length - Front Axle to Mid Tandem","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"241","MetricUnit":"mm","MetricValue":"6123","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"150"}
Length - Front Tire to Rear of Machine

351 in 8912 mm
{"Name":"Length - Front Tire to Rear of Machine","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"351","MetricUnit":"mm","MetricValue":"8912","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"151"}
Length - Front Axle to Moldboard

100 in 2552 mm
{"Name":"Length - Front Axle to Moldboard","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"100","MetricUnit":"mm","MetricValue":"2552","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"152"}
Length - Between Tandem Axles

60 in 1523 mm
{"Name":"Length - Between Tandem Axles","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"60","MetricUnit":"mm","MetricValue":"1523","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"153"}
Width - Outside Rear Tires

98.9 in 2511 mm
{"Name":"Width - Outside Rear Tires","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"98.9","MetricUnit":"mm","MetricValue":"2511","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"154"}
Width - Tire Center Lines

84.3 in 2140 mm
{"Name":"Width - Tire Center Lines","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"84.3","MetricUnit":"mm","MetricValue":"2140","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"155"}
Height - Front Axle Center

23.5 in 596 mm
{"Name":"Height - Front Axle Center","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"23.5","MetricUnit":"mm","MetricValue":"596","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"156"}
Height - Exhaust Stack

128 in 3256 mm
{"Name":"Height - Exhaust Stack","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"128","MetricUnit":"mm","MetricValue":"3256","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"157"}
Height - Top of Cylinders

120 in 3040 mm
{"Name":"Height - Top of Cylinders","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"120","MetricUnit":"mm","MetricValue":"3040","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"158"}
Ground Clearance - Rear Axle

13.3 in 339 mm
{"Name":"Ground Clearance - Rear Axle","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"13.3","MetricUnit":"mm","MetricValue":"339","Type":"measurement","SpecificationGroup":"Dimensions","SortOrder":"159"}

Engine

Base Power (1st Gear) - Net

221 hp 165 kW
{"Name":"Base Power (1st Gear) - Net","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"221","MetricUnit":"kW","MetricValue":"165","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"1"}
Engine Model

Cat® C9.3
{"Name":"Engine Model","SpecificationId":null,"TextValue":"Cat® C9.3","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"4"}
Bore

4.5 in 115 mm
{"Name":"Bore","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"4.5","MetricUnit":"mm","MetricValue":"115","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"30"}
Stroke

5.9 in 149 mm
{"Name":"Stroke","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"5.9","MetricUnit":"mm","MetricValue":"149","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"31"}
Speed at Rated Power

2,000 rpm
{"Name":"Speed at Rated Power","SpecificationId":null,"TextValue":"2,000 rpm","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"40"}
VHP Plus - Gear - Net Power - Forward 1st

221 hp 165 kW
{"Name":"VHP Plus - Gear - Net Power - Forward 1st","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"221","MetricUnit":"kW","MetricValue":"165","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Standard Capability

109 °F 43 °C
{"Name":"Standard Capability","SpecificationId":null,"TextValue":null,"EnglishUnit":"°F","EnglishValue":"109","MetricUnit":"°C","MetricValue":"43","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Torque Rise

39%
{"Name":"Torque Rise","SpecificationId":null,"TextValue":"39%","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}
VHP Plus - Gear - Net Power - Forward 8th

272 hp 203 kW
{"Name":"VHP Plus - Gear - Net Power - Forward 8th","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"272","MetricUnit":"kW","MetricValue":"203","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
VHP Plus - Gear - Net Power - Forward 3rd

241 hp 180 kW
{"Name":"VHP Plus - Gear - Net Power - Forward 3rd","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"241","MetricUnit":"kW","MetricValue":"180","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
VHP Plus - Gear - Net Power - Forward 4th

252 hp 188 kW
{"Name":"VHP Plus - Gear - Net Power - Forward 4th","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"252","MetricUnit":"kW","MetricValue":"188","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
VHP Plus - Gear - Net Power - Forward 2nd

231 hp 172 kW
{"Name":"VHP Plus - Gear - Net Power - Forward 2nd","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"231","MetricUnit":"kW","MetricValue":"172","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
VHP Plus - Gear - Net Power - Forward 6th

262 hp 195 kW
{"Name":"VHP Plus - Gear - Net Power - Forward 6th","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"262","MetricUnit":"kW","MetricValue":"195","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Maximum Torque - VHP Plus

1000 lb/ft 1355 N·m
{"Name":"Maximum Torque - VHP Plus","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb/ft","EnglishValue":"1000","MetricUnit":"N·m","MetricValue":"1355","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
VHP Plus Range - Net

165-203 kW (221-272 hp)
{"Name":"VHP Plus Range - Net","SpecificationId":null,"TextValue":"165-203 kW (221-272 hp)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}
VHP Plus - Gear - Net Power - Forward 7th

267 hp 199 kW
{"Name":"VHP Plus - Gear - Net Power - Forward 7th","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"267","MetricUnit":"kW","MetricValue":"199","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
VHP Plus - Gear - Net Power - Reverse 1st

221 hp 165 kW
{"Name":"VHP Plus - Gear - Net Power - Reverse 1st","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"221","MetricUnit":"kW","MetricValue":"165","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Base Power (1st Gear) - Net - Metric

224 hp 165 kW
{"Name":"Base Power (1st Gear) - Net - Metric","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"224","MetricUnit":"kW","MetricValue":"165","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
High Ambient - Fan Speed - Standard

1,400 rpm
{"Name":"High Ambient - Fan Speed - Standard","SpecificationId":null,"TextValue":"1,400 rpm","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}
VHP Plus - Gear - Net Power - Forward 5th

257 hp 191 kW
{"Name":"VHP Plus - Gear - Net Power - Forward 5th","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"257","MetricUnit":"kW","MetricValue":"191","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
VHP Plus - Gear - Net Power - Reverse 2nd

231 hp 172 kW
{"Name":"VHP Plus - Gear - Net Power - Reverse 2nd","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"231","MetricUnit":"kW","MetricValue":"172","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
VHP Plus Range - Net - Metric

165-203 kW (224-276 hp)
{"Name":"VHP Plus Range - Net - Metric","SpecificationId":null,"TextValue":"165-203 kW (224-276 hp)","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}
Emissions

U.S. EPA Tier 4 Final/EU Stage V
{"Name":"Emissions","SpecificationId":null,"TextValue":"U.S. EPA Tier 4 Final/EU Stage V","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}
VHP Plus - Gear - Net Power - Reverse 3rd-6th

241 hp 180 kW
{"Name":"VHP Plus - Gear - Net Power - Reverse 3rd-6th","SpecificationId":null,"TextValue":null,"EnglishUnit":"hp","EnglishValue":"241","MetricUnit":"kW","MetricValue":"180","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Displacement

567.5 in³ 9.3 l
{"Name":"Displacement","SpecificationId":null,"TextValue":null,"EnglishUnit":"in³","EnglishValue":"567.5","MetricUnit":"l","MetricValue":"9.3","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"100"}
Number of Cylinders

6
{"Name":"Number of Cylinders","SpecificationId":null,"TextValue":"6","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"129"}
Derating Altitude

10000 ft 3050 m
{"Name":"Derating Altitude","SpecificationId":null,"TextValue":null,"EnglishUnit":"ft","EnglishValue":"10000","MetricUnit":"m","MetricValue":"3050","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"130"}
High Ambient - Fan Speed - Maximum

1,550 rpm
{"Name":"High Ambient - Fan Speed - Maximum","SpecificationId":null,"TextValue":"1,550 rpm","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"134"}
High Ambient - Fan Speed - Minimum

500 rpm
{"Name":"High Ambient - Fan Speed - Minimum","SpecificationId":null,"TextValue":"500 rpm","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"135"}
High - Ambient Capability

122 °F 50 °C
{"Name":"High - Ambient Capability","SpecificationId":null,"TextValue":null,"EnglishUnit":"°F","EnglishValue":"122","MetricUnit":"°C","MetricValue":"50","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"136"}

Frame

Drawbar - Width

3 in 76.2 mm
{"Name":"Drawbar - Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"3","MetricUnit":"mm","MetricValue":"76.2","Type":"measurement","SpecificationGroup":"Frame","SortOrder":"50"}
Circle - Diameter

61.1 in 1553 mm
{"Name":"Circle - Diameter","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"61.1","MetricUnit":"mm","MetricValue":"1553","Type":"measurement","SpecificationGroup":"Frame","SortOrder":"69"}
Circle - Blade Beam Thickness

1.6 in 40 mm
{"Name":"Circle - Blade Beam Thickness","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"1.6","MetricUnit":"mm","MetricValue":"40","Type":"measurement","SpecificationGroup":"Frame","SortOrder":"70"}
Drawbar - Height

6 in 152 mm
{"Name":"Drawbar - Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"6","MetricUnit":"mm","MetricValue":"152","Type":"measurement","SpecificationGroup":"Frame","SortOrder":"71"}
Front Frame Structure - Width

12 in 305 mm
{"Name":"Front Frame Structure - Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"12","MetricUnit":"mm","MetricValue":"305","Type":"measurement","SpecificationGroup":"Frame","SortOrder":"99"}
Circle - Height

6.3 in 160 mm
{"Name":"Circle - Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"6.3","MetricUnit":"mm","MetricValue":"160","Type":"measurement","SpecificationGroup":"Frame","SortOrder":"99"}
Front Frame Structure - Height

12.6 in 321 mm
{"Name":"Front Frame Structure - Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"12.6","MetricUnit":"mm","MetricValue":"321","Type":"measurement","SpecificationGroup":"Frame","SortOrder":"99"}
Drawbar - Thickness

0.5 in 12.7 mm
{"Name":"Drawbar - Thickness","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"0.5","MetricUnit":"mm","MetricValue":"12.7","Type":"measurement","SpecificationGroup":"Frame","SortOrder":"101"}
Front-Top/Bottom Plate - Width

12 in 305 mm
{"Name":"Front-Top/Bottom Plate - Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"12","MetricUnit":"mm","MetricValue":"305","Type":"measurement","SpecificationGroup":"Frame","SortOrder":"118"}
Front-Top/Bottom Plate - Thickness

0.87 in 22 mm
{"Name":"Front-Top/Bottom Plate - Thickness","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"0.87","MetricUnit":"mm","MetricValue":"22","Type":"measurement","SpecificationGroup":"Frame","SortOrder":"119"}
Front Axle - Height to Center

23.5 in 596 mm
{"Name":"Front Axle - Height to Center","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"23.5","MetricUnit":"mm","MetricValue":"596","Type":"measurement","SpecificationGroup":"Frame","SortOrder":"126"}
Front Axle - Wheel Lean - Left/Right

18°
{"Name":"Front Axle - Wheel Lean - Left/Right","SpecificationId":null,"TextValue":"18°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Frame","SortOrder":"127"}
Front Axle - Total Oscillation per Side

32°
{"Name":"Front Axle - Total Oscillation per Side","SpecificationId":null,"TextValue":"32°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Frame","SortOrder":"128"}

Hydraulic System

Circuit Type

Parallel
{"Name":"Circuit Type","SpecificationId":null,"TextValue":"Parallel","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Hydraulic System","SortOrder":"45"}
Pump Type

Variable Piston
{"Name":"Pump Type","SpecificationId":null,"TextValue":"Variable Piston","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Hydraulic System","SortOrder":"46"}
Pump Output

55.5 gal/min 210 l/min
{"Name":"Pump Output","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal/min","EnglishValue":"55.5","MetricUnit":"l/min","MetricValue":"210","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"47"}
Maximum System Pressure

3503 psi 24150 kPa
{"Name":"Maximum System Pressure","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"3503","MetricUnit":"kPa","MetricValue":"24150","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"48"}
Reservoir Tank Capacity

16.9 gal (US) 64 l
{"Name":"Reservoir Tank Capacity","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"16.9","MetricUnit":"l","MetricValue":"64","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"49"}
Standby Pressure

885 psi 6100 kPa
{"Name":"Standby Pressure","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"885","MetricUnit":"kPa","MetricValue":"6100","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"50"}

Moldboard

Blade Width

14 ft 4.2 m
{"Name":"Blade Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"ft","EnglishValue":"14","MetricUnit":"m","MetricValue":"4.2","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"3"}
Moldboard - Height

24 in 610 mm
{"Name":"Moldboard - Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"24","MetricUnit":"mm","MetricValue":"610","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"73"}
Moldboard - Thickness

0.87 in 22 mm
{"Name":"Moldboard - Thickness","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"0.87","MetricUnit":"mm","MetricValue":"22","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"74"}
Arc Radius

16.3 in 413 mm
{"Name":"Arc Radius","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"16.3","MetricUnit":"mm","MetricValue":"413","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"75"}
Throat Clearance

6.5 in 166 mm
{"Name":"Throat Clearance","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"6.5","MetricUnit":"mm","MetricValue":"166","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"76"}
Cutting Edge Width

6 in 152 mm
{"Name":"Cutting Edge Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"6","MetricUnit":"mm","MetricValue":"152","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"77"}
Cutting Edge Thickness

0.6 in 16 mm
{"Name":"Cutting Edge Thickness","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"0.6","MetricUnit":"mm","MetricValue":"16","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"78"}
End Bit - Width

6 in 152 mm
{"Name":"End Bit - Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"6","MetricUnit":"mm","MetricValue":"152","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"79"}
End Bit - Thickness

0.6 in 16 mm
{"Name":"End Bit - Thickness","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"0.6","MetricUnit":"mm","MetricValue":"16","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"80"}
Blade Pull - Base GVW

25931 lb 11762 kg
{"Name":"Blade Pull - Base GVW","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"25931","MetricUnit":"kg","MetricValue":"11762","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"81"}
Blade Pull - Maximum GVW

34262 lb 15541 kg
{"Name":"Blade Pull - Maximum GVW","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"34262","MetricUnit":"kg","MetricValue":"15541","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"82"}
Blade Down Pressure - Base GVW

17004 lb 7713 kg
{"Name":"Blade Down Pressure - Base GVW","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"17004","MetricUnit":"kg","MetricValue":"7713","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"85"}
Blade Down Pressure - Maximum GVW

29308 lb 13294 kg
{"Name":"Blade Down Pressure - Maximum GVW","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"29308","MetricUnit":"kg","MetricValue":"13294","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"86"}
Moldboard - Blade Width

14 ft 4.2 m
{"Name":"Moldboard - Blade Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"ft","EnglishValue":"14","MetricUnit":"m","MetricValue":"4.2","Type":"measurement","SpecificationGroup":"Moldboard","SortOrder":"99"}

Operating Specifications

Top Speed - Forward

29.5 mile/h 47.4 km/h
{"Name":"Top Speed - Forward","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"29.5","MetricUnit":"km/h","MetricValue":"47.4","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"33"}
Top Speed - Reverse

23.3 mile/h 37.4 km/h
{"Name":"Top Speed - Reverse","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"23.3","MetricUnit":"km/h","MetricValue":"37.4","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"34"}
Turning Radius - Outside Front Tires

25.59 ft 7.8 m
{"Name":"Turning Radius - Outside Front Tires","SpecificationId":null,"TextValue":null,"EnglishUnit":"ft","EnglishValue":"25.59","MetricUnit":"m","MetricValue":"7.8","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"35"}
Steering Range - Left/Right

50°
{"Name":"Steering Range - Left/Right","SpecificationId":null,"TextValue":"50°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Operating Specifications","SortOrder":"36"}
Articulation Angle - Left/Right

20°
{"Name":"Articulation Angle - Left/Right","SpecificationId":null,"TextValue":"20°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Operating Specifications","SortOrder":"37"}
Forward - 1st

2.6 mile/h 4.1 km/h
{"Name":"Forward - 1st","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"2.6","MetricUnit":"km/h","MetricValue":"4.1","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"51"}
Forward - 2nd

3.5 mile/h 5.6 km/h
{"Name":"Forward - 2nd","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"3.5","MetricUnit":"km/h","MetricValue":"5.6","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"52"}
Forward - 3rd

5.1 mile/h 8.1 km/h
{"Name":"Forward - 3rd","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"5.1","MetricUnit":"km/h","MetricValue":"8.1","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"53"}
Forward - 4th

7 mile/h 11.2 km/h
{"Name":"Forward - 4th","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"7","MetricUnit":"km/h","MetricValue":"11.2","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"54"}
Forward - 5th

10.8 mile/h 17.4 km/h
{"Name":"Forward - 5th","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"10.8","MetricUnit":"km/h","MetricValue":"17.4","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"55"}
Forward - 6th

14.7 mile/h 23.7 km/h
{"Name":"Forward - 6th","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"14.7","MetricUnit":"km/h","MetricValue":"23.7","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"56"}
Forward - 7th

20.3 mile/h 32.6 km/h
{"Name":"Forward - 7th","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"20.3","MetricUnit":"km/h","MetricValue":"32.6","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"57"}
Forward - 8th

29.5 mile/h 47.4 km/h
{"Name":"Forward - 8th","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"29.5","MetricUnit":"km/h","MetricValue":"47.4","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"58"}
Reverse - 1st

2 mile/h 3.3 km/h
{"Name":"Reverse - 1st","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"2","MetricUnit":"km/h","MetricValue":"3.3","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"59"}
Reverse - 2nd

3.8 mile/h 6.1 km/h
{"Name":"Reverse - 2nd","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"3.8","MetricUnit":"km/h","MetricValue":"6.1","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"60"}
Reverse - 3rd

5.5 mile/h 8.8 km/h
{"Name":"Reverse - 3rd","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"5.5","MetricUnit":"km/h","MetricValue":"8.8","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"61"}
Reverse - 4th

8.5 mile/h 13.7 km/h
{"Name":"Reverse - 4th","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"8.5","MetricUnit":"km/h","MetricValue":"13.7","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"62"}
Reverse - 5th

16 mile/h 25.7 km/h
{"Name":"Reverse - 5th","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"16","MetricUnit":"km/h","MetricValue":"25.7","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"63"}
Reverse - 6th

23.3 mile/h 37.4 km/h
{"Name":"Reverse - 6th","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"23.3","MetricUnit":"km/h","MetricValue":"37.4","Type":"measurement","SpecificationGroup":"Operating Specifications","SortOrder":"64"}

Power Train

Forward/Reverse Gears

8 Forward/6 Reverse
{"Name":"Forward/Reverse Gears","SpecificationId":null,"TextValue":"8 Forward/6 Reverse","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Power Train","SortOrder":"41"}
Transmission

APECS, Direct Drive, Powershift
{"Name":"Transmission","SpecificationId":null,"TextValue":"APECS, Direct Drive, Powershift","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Power Train","SortOrder":"42"}
Brakes - Service

Multiple Oil Disc
{"Name":"Brakes - Service","SpecificationId":null,"TextValue":"Multiple Oil Disc","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Power Train","SortOrder":"43"}
Brakes - Service - Surface Area

3565 in² 23000 cm²
{"Name":"Brakes - Service - Surface Area","SpecificationId":null,"TextValue":null,"EnglishUnit":"in²","EnglishValue":"3565","MetricUnit":"cm²","MetricValue":"23000","Type":"measurement","SpecificationGroup":"Power Train","SortOrder":"44"}
Brakes - Parking

Multiple Oil Disc
{"Name":"Brakes - Parking","SpecificationId":null,"TextValue":"Multiple Oil Disc","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Power Train","SortOrder":"67"}
Brakes - Secondary

Dual Circuit Control
{"Name":"Brakes - Secondary","SpecificationId":null,"TextValue":"Dual Circuit Control","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Power Train","SortOrder":"68"}

Ripper

Ripping Depth - Maximum

16.8 in 426 mm
{"Name":"Ripping Depth - Maximum","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"16.8","MetricUnit":"mm","MetricValue":"426","Type":"measurement","SpecificationGroup":"Ripper","SortOrder":"99"}
Ripper Shank Holder Spacing

21 in 533 mm
{"Name":"Ripper Shank Holder Spacing","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"21","MetricUnit":"mm","MetricValue":"533","Type":"measurement","SpecificationGroup":"Ripper","SortOrder":"99"}
Ripper Shank Holders

5
{"Name":"Ripper Shank Holders","SpecificationId":null,"TextValue":"5","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Ripper","SortOrder":"100"}
Penetration Force

20812 lb 9440 kg
{"Name":"Penetration Force","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"20812","MetricUnit":"kg","MetricValue":"9440","Type":"measurement","SpecificationGroup":"Ripper","SortOrder":"103"}
Pry-Out Force

28493 lb 12924 kg
{"Name":"Pry-Out Force","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"28493","MetricUnit":"kg","MetricValue":"12924","Type":"measurement","SpecificationGroup":"Ripper","SortOrder":"104"}
Machine Length Increase, Beam Raised

40.6 in 1031 mm
{"Name":"Machine Length Increase, Beam Raised","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"40.6","MetricUnit":"mm","MetricValue":"1031","Type":"measurement","SpecificationGroup":"Ripper","SortOrder":"105"}

Scarifier

Front, V-Type, 5 or 11 Tooth - Scarifier Shank Holder Spacing

4.6 in 116 mm
{"Name":"Front, V-Type, 5 or 11 Tooth - Scarifier Shank Holder Spacing","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"4.6","MetricUnit":"mm","MetricValue":"116","Type":"measurement","SpecificationGroup":"Scarifier","SortOrder":"99"}
Front, V-Type, 5 or 11 Tooth - Scarifying Depth, Maximum

18.4 in 467 mm
{"Name":"Front, V-Type, 5 or 11 Tooth - Scarifying Depth, Maximum","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"18.4","MetricUnit":"mm","MetricValue":"467","Type":"measurement","SpecificationGroup":"Scarifier","SortOrder":"99"}
Mid, V-Type - Working Width

46.6 in 1184 mm
{"Name":"Mid, V-Type - Working Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"46.6","MetricUnit":"mm","MetricValue":"1184","Type":"measurement","SpecificationGroup":"Scarifier","SortOrder":"99"}
Rear - Scarifying Depth, Maximum

16.8 in 426 mm
{"Name":"Rear - Scarifying Depth, Maximum","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"16.8","MetricUnit":"mm","MetricValue":"426","Type":"measurement","SpecificationGroup":"Scarifier","SortOrder":"99"}
Front, V-Type - Working Width

47.4 in 1205 mm
{"Name":"Front, V-Type - Working Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"47.4","MetricUnit":"mm","MetricValue":"1205","Type":"measurement","SpecificationGroup":"Scarifier","SortOrder":"99"}
Mid, V-Type - Scarifier Shank Holder Spacing

4.6 in 116 mm
{"Name":"Mid, V-Type - Scarifier Shank Holder Spacing","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"4.6","MetricUnit":"mm","MetricValue":"116","Type":"measurement","SpecificationGroup":"Scarifier","SortOrder":"99"}
Mid, V-Type - Scarifying Depth, Maximum

11.5 in 292 mm
{"Name":"Mid, V-Type - Scarifying Depth, Maximum","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"11.5","MetricUnit":"mm","MetricValue":"292","Type":"measurement","SpecificationGroup":"Scarifier","SortOrder":"99"}
Front, V-Type, 5 or 11 Tooth - Scarifier Shank Holders

5/11
{"Name":"Front, V-Type, 5 or 11 Tooth - Scarifier Shank Holders","SpecificationId":null,"TextValue":"5/11","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Scarifier","SortOrder":"99"}
Front, V-Type, 5 or 11 Tooth - Working Width

40.6 in 1031 mm
{"Name":"Front, V-Type, 5 or 11 Tooth - Working Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"40.6","MetricUnit":"mm","MetricValue":"1031","Type":"measurement","SpecificationGroup":"Scarifier","SortOrder":"99"}
Mid, V-Type - Scarifier Shank Holders

11
{"Name":"Mid, V-Type - Scarifier Shank Holders","SpecificationId":null,"TextValue":"11","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Scarifier","SortOrder":"99"}
Rear - Working Width

84 in 2133 mm
{"Name":"Rear - Working Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"84","MetricUnit":"mm","MetricValue":"2133","Type":"measurement","SpecificationGroup":"Scarifier","SortOrder":"114"}
Rear - Scarifier Shank Holders

9
{"Name":"Rear - Scarifier Shank Holders","SpecificationId":null,"TextValue":"9","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Scarifier","SortOrder":"116"}
Rear - Scarifier Shank Holder Spacing

10.5 in 267 mm
{"Name":"Rear - Scarifier Shank Holder Spacing","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"10.5","MetricUnit":"mm","MetricValue":"267","Type":"measurement","SpecificationGroup":"Scarifier","SortOrder":"117"}

Service Refill

Fuel Capacity

104 gal (US) 394 l
{"Name":"Fuel Capacity","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"104","MetricUnit":"l","MetricValue":"394","Type":"measurement","SpecificationGroup":"Service Refill","SortOrder":"38"}
Cooling System

15 gal (US) 57 l
{"Name":"Cooling System","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"15","MetricUnit":"l","MetricValue":"57","Type":"measurement","SpecificationGroup":"Service Refill","SortOrder":"96"}
Hydraulic System - Total

26.4 gal (US) 100 l
{"Name":"Hydraulic System - Total","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"26.4","MetricUnit":"l","MetricValue":"100","Type":"measurement","SpecificationGroup":"Service Refill","SortOrder":"97"}
Hydraulic System - Tank

16.9 gal (US) 64 l
{"Name":"Hydraulic System - Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"16.9","MetricUnit":"l","MetricValue":"64","Type":"measurement","SpecificationGroup":"Service Refill","SortOrder":"98"}
Transmission - Differential - Final Drives

18.5 gal (US) 70 l
{"Name":"Transmission - Differential - Final Drives","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"18.5","MetricUnit":"l","MetricValue":"70","Type":"measurement","SpecificationGroup":"Service Refill","SortOrder":"99"}
Diesel Exhaust Fluid

5.8 gal (US) 22 l
{"Name":"Diesel Exhaust Fluid","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"5.8","MetricUnit":"l","MetricValue":"22","Type":"measurement","SpecificationGroup":"Service Refill","SortOrder":"99"}
Engine Oil

7.9 gal (US) 30 l
{"Name":"Engine Oil","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"7.9","MetricUnit":"l","MetricValue":"30","Type":"measurement","SpecificationGroup":"Service Refill","SortOrder":"160"}
Tandem Housing - Each

22.9 gal (US) 87 l
{"Name":"Tandem Housing - Each","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"22.9","MetricUnit":"l","MetricValue":"87","Type":"measurement","SpecificationGroup":"Service Refill","SortOrder":"162"}
Front Wheel Spindle Bearing Housing

0.13 gal (US) 0.5 l
{"Name":"Front Wheel Spindle Bearing Housing","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"0.13","MetricUnit":"l","MetricValue":"0.5","Type":"measurement","SpecificationGroup":"Service Refill","SortOrder":"163"}
Circle Drive Housing

1.8 gal (US) 7 l
{"Name":"Circle Drive Housing","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"1.8","MetricUnit":"l","MetricValue":"7","Type":"measurement","SpecificationGroup":"Service Refill","SortOrder":"164"}

Standards

Brakes

ISO 3450
{"Name":"Brakes","SpecificationId":null,"TextValue":"ISO 3450","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Standards","SortOrder":"99"}
ROPS/FOPS

ISO 3471; ISO 3449
{"Name":"ROPS/FOPS","SpecificationId":null,"TextValue":"ISO 3471; ISO 3449","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Standards","SortOrder":"99"}
Steering

ISO 5010
{"Name":"Steering","SpecificationId":null,"TextValue":"ISO 5010","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Standards","SortOrder":"99"}
Sound

ISO 6394; ISO 6395
{"Name":"Sound","SpecificationId":null,"TextValue":"ISO 6394; ISO 6395","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Standards","SortOrder":"99"}

Tandems

Height

22.5 in 572 mm
{"Name":"Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"22.5","MetricUnit":"mm","MetricValue":"572","Type":"measurement","SpecificationGroup":"Tandems","SortOrder":"137"}
Width

8 in 204 mm
{"Name":"Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"8","MetricUnit":"mm","MetricValue":"204","Type":"measurement","SpecificationGroup":"Tandems","SortOrder":"138"}
Sidewall Thickness - Inner

0.69 in 17.5 mm
{"Name":"Sidewall Thickness - Inner","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"0.69","MetricUnit":"mm","MetricValue":"17.5","Type":"measurement","SpecificationGroup":"Tandems","SortOrder":"139"}
Sidewall Thickness - Outer

0.71 in 18 mm
{"Name":"Sidewall Thickness - Outer","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"0.71","MetricUnit":"mm","MetricValue":"18","Type":"measurement","SpecificationGroup":"Tandems","SortOrder":"140"}
Drive Chain Pitch

2 in 50.8 mm
{"Name":"Drive Chain Pitch","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"2","MetricUnit":"mm","MetricValue":"50.8","Type":"measurement","SpecificationGroup":"Tandems","SortOrder":"141"}
Wheel Axle Spacing

60 in 1523 mm
{"Name":"Wheel Axle Spacing","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"60","MetricUnit":"mm","MetricValue":"1523","Type":"measurement","SpecificationGroup":"Tandems","SortOrder":"142"}
Tandem Oscillation - Front Up

15°
{"Name":"Tandem Oscillation - Front Up","SpecificationId":null,"TextValue":"15°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Tandems","SortOrder":"143"}
Tandem Oscillation - Front Down

25°
{"Name":"Tandem Oscillation - Front Down","SpecificationId":null,"TextValue":"25°","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Tandems","SortOrder":"144"}

Weights

Operating Weight - Typically Equipped

45547 lb 20660 kg
{"Name":"Operating Weight - Typically Equipped","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"45547","MetricUnit":"kg","MetricValue":"20660","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"2"}
Gross Vehicle Weight - Maximum - Rear Axle

38069 lb 17268 kg
{"Name":"Gross Vehicle Weight - Maximum - Rear Axle","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"38069","MetricUnit":"kg","MetricValue":"17268","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"22"}
Gross Vehicle Weight - Base - Front Axle

9907 lb 4494 kg
{"Name":"Gross Vehicle Weight - Base - Front Axle","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"9907","MetricUnit":"kg","MetricValue":"4494","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"27"}
Gross Vehicle Weight - Base - Rear Axle

28812 lb 13069 kg
{"Name":"Gross Vehicle Weight - Base - Rear Axle","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"28812","MetricUnit":"kg","MetricValue":"13069","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"28"}
Gross Vehicle Weight - Maximum - Total

55144 lb 25013 kg
{"Name":"Gross Vehicle Weight - Maximum - Total","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"55144","MetricUnit":"kg","MetricValue":"25013","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"29"}
Operating Weight - Typically Equipped - Front Axle

13237 lb 6004 kg
{"Name":"Operating Weight - Typically Equipped - Front Axle","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"13237","MetricUnit":"kg","MetricValue":"6004","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
Gross Vehicle Weight - Base - Total

38719 lb 17563 kg
{"Name":"Gross Vehicle Weight - Base - Total","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"38719","MetricUnit":"kg","MetricValue":"17563","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
Gross Vehicle Weight - Maximum - Front Axle

17075 lb 7745 kg
{"Name":"Gross Vehicle Weight - Maximum - Front Axle","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"17075","MetricUnit":"kg","MetricValue":"7745","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
Operating Weight - Typically Equipped - Total

45547 lb 20660 kg
{"Name":"Operating Weight - Typically Equipped - Total","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"45547","MetricUnit":"kg","MetricValue":"20660","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
Operating Weight - Typically Equipped - Rear Axle

32310 lb 14656 kg
{"Name":"Operating Weight - Typically Equipped - Rear Axle","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"32310","MetricUnit":"kg","MetricValue":"14656","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}

Benefits

DESIGNED FOR OPERATORS

Good visibility is key to safety and efficiency. Angled cab doors, tapered engine enclosure and a sloped rear window make it easy to see the moldboard and tires, as well as behind the machine. Optional rear vision camera further enhances lines of sight all around the machine.
Experience the most spacious, comfortable cab in the industry.
Easy-to-learn joystick controls replace levers, so hand and arm movement is reduced by 78%, helping reduce operator fatigue for better productivity.
Left joystick controls steering, articulation, return-to-center, wheel lean, gear selection, left moldboard lift cylinder and float.
Right joystick controls drawbar, circle and moldboard functions as well as electronic throttle control and manual differential lock/unlock.
Joystick lean angle mirrors the steer tires' turning angle.
A brake tensioning system holds the joystick in position until the operator moves it.
Steering control automatically reduces sensitivity at higher ground speeds for predictable control.
Infinitely variable roller switches control the rear ripper and/or front lift group (when equipped).
Control switches are in easy reach.
Updated seat offers softer cushions, three-position tilt and optional heated and heated/cooled cushions.
Control pods are electronically positioned allowing each operator to set the ideal operating position.
Multiple isolation mounts reduce sound and vibration for a more relaxed work environment.
High capacity Heating, Ventilation and Air Conditioning (HVAC) system dehumidifies and pressurizes the cab, circulates fresh air, seals out dust and keeps windows clear.
An optional deluxe radio with CD features MP3 and Bluetooth® technology.
New Message Display shows machine performance and diagnostic information. Located in center console, it also displays Grade Control Cross Slope readings.
Electronic Throttle Control helps improve productivity by providing the best match of horsepower and torque for the demands of the application.
Articulation Return-to-Center automatically returns the machine to a straight frame position from any angle with the touch of a button.
Select Fine, Normal or Coarse blade lift modulation to best fit application or operator preference.

POWERFUL EFFICIENCY

Cat C9.3 engine delivers the performance needed to maintain consistent grading speeds for maximum productivity.
Latest engine technology optimize productivity, fuel efficiency, reliability, life and minimize emissions.
Hydraulic demand fan automatically adjusts speed according to engine cooling requirements. When cooling demand is reduced, you benefit from more power to the ground and improved fuel efficiency.
Engine Idle Shutdown Timer is software-enabled by your Cat dealer to shut down the engine after a set period of time to save you fuel and help reduce emissions.
Optional Reversing Fan, clears debris on-the-go.
The Motor Gradersgive you efficiency and longevity in your most demanding applications.
Standard Automatic Differential Lock/Unlock unlocks the differential during a turn and re-locks when straight for easier operation and to help protect the power train.
Full Electronic Clutch Pressure Control system optimizes inching modulation for smooth shifts and directional changes, reducing stress on gears.
Programmable AutoShift option simplifies operation by allowing the operator to program the transmission to shift at optimal points to match your application.
Eco Mode can be engaged for up to 10% fuel savings depending upon application.
Power Shift Countershaft Transmission is matched to the Cat engine to maximize power to the ground.
Wide operating gear range for maximum productivity.
Engine Over-Speed Protection prevents downshifting until an acceptable safe travel speed has been established.
Sealed spindle keeps front axle bearings lubricated and protected from contaminants. The Cat “Live Spindle” design places the larger tapered roller bearing on the outside, where the load is greater, extending bearing life.
Bolt-on modular rear axle improves serviceability and contamination control with easy access to differential components.
Oil-bath, multi-disc service brakes are hydraulically actuated for smooth, predictable braking and lower operating costs. Brakes are located at each tandem wheel and have a large total brake surface area to give you dependable stopping power and longer life.
Emissions technology is transparent with no action required from the operator or need to stop. Regeneration runs automatically at cold start-up and, if needed, in the background while you work.
Reaching Tier 4 Final standards only required one additional system to the proven Cat emission strategy - Selective Catalytic Reduction (SCR).
SCR utilizes Diesel Exhaust Fluid (DEF), conveniently filled from ground level when re-fueling.
A gauge on the dash shows your fluid level.
At shutdown, a pump automatically purges the DEF lines.
If the engine/aftertreatment temperatures are high, a Delayed Engine Shutdown will activate automatically to cool the machine and then purge the lines.

HEAVY DUTY CONSTRUCTION

Caterpillar designs motor grader frame and drawbar components to give you performance and durability.
The one-piece forged steel circle stands up to high stress loads, and a sacrificial wear system helps keep your service time and costs down.
Articulation hitch features a large tapered roller bearing to carry loads evenly and smoothly. It is sealed to prevent contamination and a locking pin prevents articulation during service or transport.
The drawbar, circle and moldboard make it easy for you to keep the components tight.
Shims and patented top-adjust wear strips are easy to add or replace, reducing downtime.
Durable nylon composite wear inserts maximize circle torque and component life.
Sacrificial brass wear strips between the blade mounting group and moldboard can be easily adjusted and replaced.
Shim less Moldboard Retention System uses vertical and horizontal adjusting screws to keep moldboard wear strips aligned for reduced blade chatter and precise blade control.
An aggressive blade angle, optimized moldboard curvature and large throat clearance help you work more efficiently by allowing material to roll more freely along the blade.
Heat-treated rails, hardened cutting edges and end bits, and heavy duty bolts to give you greater moldboard reliability and long service life.
Link bar allows extreme moldboard positioning for easier bank sloping and ditch cutting/cleaning.
Proven load-sensing hydraulic system and advanced electro-hydraulics give you superior implement control and responsive performance that makes operator's jobs easier. Continuously matching hydraulic flow/pressure to power demands creates less heat and reduces power consumption.
Consistent, Predictable Movement - Proportional Priority Pressure-Compensating (PPP-C) valves have different flow rates for the head and rod ends of the cylinder, so you can count on consistent, predictable implement response.
Balanced Flow - Hydraulic flow is proportioned to give you confidence that all implements will operate simultaneously without slowing the engine or speed of some implements.
Blade can float freely under its own weight. By floating both cylinders, the blade can follow the contours of the ground. Floating only one cylinder permits the toe of the blade to follow a hard surface while the operator controls the slope with the other lift cylinder.
Large, separate hydraulic oil supplies prevent cross-contamination and provide proper oil cooling, reducing heat build-up and extending component life.
Cat XT™ hose allows high pressures for maximum power and reduced downtime.

TECHNOLOGY THAT GETS WORK DONE

Cat technologies makes smart use of technology and services to improve job site efficiency. Using the data from technology equipped machines, get more information and insight into equipment and operations
Cat technologies offer improvements in these key areas:
Equipment Management - increase uptime and reduce operating costs.
Productivity - monitor production and manage job site efficiency.
Safety - enhance job site awareness to keep your people and equipment safe.
Featured Cat technologies include -

Link technologies that provide wireless capability to machines enabling two-way transfer of information collected by on-board sensors, control modules, and other Cat technologies using off-board apps, such as Cat VisionLink® software.
Cat Product Link/VisionLink is deeply integrated, helping take guesswork out of equipment management. Easy access to timely information like machine location, hours, fuel usage, idle time and event codes via the online VisionLink user interface helps effectively manage fleet and lower operating costs.
Grade technologies combine digital design data, in-cab guidance, and automatic blade controls to enhance grading accuracy, reduce rework, and lower costs related to production earthmoving and rough, fine and finish grade applications.
Cat Grade with Cross Slope is an optional, factory installed system that helps improve grading efficiency and more easily maintain accurate cross slopes. The system automatically controls one side of the blade, reducing manual operator inputs by as much as 50 percent. Experienced operators can maintain peak efficiency levels throughout more of the work day, while less experienced operators can be more productive faster. The system is job-ready from day one, and scalable for the future with upgrade kits that provide additional 2D and/or 3D control.

Cat Messenger, combined with full systems integration, enhances diagnostic capability for quick analysis of critical data.
Electronic Technician (Cat ET) lets service technicians access stored diagnostic data and configure machine parameters through the Cat Data Link.
Low Battery Elevated Idle raises idle speed when low system voltage is detected, ensuring adequate system voltage and improving battery reliability.
Automatic Engine Deration protects the engine by automatically lowering engine torque output and alerting the operator if critical conditions are detected.
Manage your fleet of machines while reducing fuel burn with Cat Production Measurement System option. The Efficiency Coach and Application Segmentation work together to monitor operators and machines simultaneously. Measure your jobsite’s efficiency and productivity from anywhere on the website.

SAFETY FIRST

Operator Presence Monitor keeps the parking brake engaged and hydraulic implements disabled until the operator is seated and the machine is ready for operation.
Speed Sensitive Steering lessens steering sensitivity as ground speed increases for greater operator confidence and control.
Secondary Steering System's electric hydraulic pump automatically engages in case of a drop in steering pressure to ensure operator can steer the machine to a stop.
Hydraulic lockout disables all implement functions while still providing machine steering control. Especially useful while roading.
Brakes are located at each tandem wheel to eliminate braking loads on the power train. Redundant brake systems utilize accumulators to enable stopping in case of machine failure.
Perforated steel tandem walkways and convenient grab rails provide a sturdy platform when moving on, off and around the machine.
Circle Drive Slip Clutch protects the drawbar, circle and moldboard from shock loads if the blade encounters an immovable object and also reduces the possibility of abrupt directional changes in poor traction conditions.
Blade Lift Accumulators help absorb impact loads by allowing vertical blade travel. This optional feature reduces wear and impact loading for enhanced operator safety.
Safety Features -

Optional rearview camera with in-cab monitor
New, optional seat belt indicator light reminds operator to fasten safety belt
Grouped, ground level service points
Laminated front window glass
Optional LED Lighting
Ground-level electrical disconnect switch
Ground-level engine shutoff switch
Anti-glare paint eases night operation
Optional front and rear fenders

TOP-TIER SERVICE AND SUPPORT

Cat motor graders are designed to help you increase uptime and reduce costs.
Grouped service points and extended service intervals save maintenance time.
New, optional LED lights in the left hand compartments make it more convenient to service the machine in low light.
Cat dealers are second to none. From machine selection and purchase to maintenance support, operator training and rebuilds, Cat dealers have the experience and capabilities to help keep you up and running at peak performance.

SUSTAINABILITY

The Cat® C9.3 engine meets U.S. EPA Tier 4 Final and EU Stage V emission standards.
Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester) * or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details.
Engine Idle Shutdown Timer reduces fuel burn, greenhouse gas emissions and unnecessary idle time by shutting down the machine after a pre-set idling period.
Cat® Grade helps reduce fuel burn and greenhouse gas emissions by enabling you to achieve grade faster and more accurately by automating blade actions.
Extended maintenance intervals not only reduce downtime but decrease the amount of fluid and filters that are replaced over the life of the machine.
VisionLink® displays the CO2 emissions for monitored assets, calculated by fuel type for the Runtime Fuel Burned each day in a selected date range.
Don't waste fuel idling. Cat VisionLink® online fleet monitoring helps you manage idle time and reduce fuel burn and greenhouse gas emissions.
Cat® Reman parts are a sustainable choice. New Cat parts are designed with the potential to have more than one life, so Cat Reman parts are truly remanufactured — not just repaired, rebuilt or reconditioned. Because the process ensures the latest design changes are incorporated into Cat Reman parts, you get like new quality and outstanding performance at lower cost.

*Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer).

Equipment Info

NOTE

Standard and optional equipment may vary. Consult your Cat dealer for details.

POWER TRAIN

Air cleaner, dual stage, dry type, diesel, with automatic engine derate and automatic dust ejector, service indicator through Cat Messenger

ELECTRICAL

Alarm, back up

OPERATOR ENVIRONMENT

Accelerator

FLUIDS

Antifreeze

TIRES, RIMS AND WHEELS

Partial allowance for tires on 254 — 607 mm (10 — 24 in) multi-piece rims is included in the base machine price and weight

OTHER STANDARD EQUIPMENT

Accumulators, brake, dual certified

Product Brochures

Product Brochure #1

Product Brochure #2
