415

Axle Ratings

Front Axle, AWD - Static

51808 lb 23500 kg
{"Name":"Front Axle, AWD - Static","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"51808","MetricUnit":"kg","MetricValue":"23500","Type":"measurement","SpecificationGroup":"Axle Ratings","SortOrder":"99"}
Front Axle, AWD - Dynamic

19841 lb 9000 kg
{"Name":"Front Axle, AWD - Dynamic","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"19841","MetricUnit":"kg","MetricValue":"9000","Type":"measurement","SpecificationGroup":"Axle Ratings","SortOrder":"99"}
Rear Axle - Static

58422 lb 26500 kg
{"Name":"Rear Axle - Static","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"58422","MetricUnit":"kg","MetricValue":"26500","Type":"measurement","SpecificationGroup":"Axle Ratings","SortOrder":"99"}
Rear Axle - Dynamic

22046 lb 10000 kg
{"Name":"Rear Axle - Dynamic","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"22046","MetricUnit":"kg","MetricValue":"10000","Type":"measurement","SpecificationGroup":"Axle Ratings","SortOrder":"99"}

Backhoe

Dig Depth - Standard

14 ft 4277 mm
{"Name":"Dig Depth - Standard","SpecificationId":null,"TextValue":null,"EnglishUnit":"ft","EnglishValue":"14","MetricUnit":"mm","MetricValue":"4277","Type":"measurement","SpecificationGroup":"Backhoe","SortOrder":"2"}

Engine

Net Power - SAE J1349

70 HP 52 kW
{"Name":"Net Power - SAE J1349","SpecificationId":null,"TextValue":null,"EnglishUnit":"HP","EnglishValue":"70","MetricUnit":"kW","MetricValue":"52","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"1"}
Displacement

220 in³ 3.6 l
{"Name":"Displacement","SpecificationId":null,"TextValue":null,"EnglishUnit":"in³","EnglishValue":"220","MetricUnit":"l","MetricValue":"3.6","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"90"}
Emissions

Engine meets U.S. EPA Tier 4 Final/EU Stage V emission standards.
{"Name":"Emissions","SpecificationId":null,"TextValue":"Engine meets U.S. EPA Tier 4 Final/EU Stage V emission standards.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}
Net Power Rating at 2,200 rpm - SAE J1349

70 HP 52 kW
{"Name":"Net Power Rating at 2,200 rpm - SAE J1349","SpecificationId":null,"TextValue":null,"EnglishUnit":"HP","EnglishValue":"70","MetricUnit":"kW","MetricValue":"52","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Net Power Rating at 2,200 rpm - ISO 9249

69 HP 52 kW
{"Name":"Net Power Rating at 2,200 rpm - ISO 9249","SpecificationId":null,"TextValue":null,"EnglishUnit":"HP","EnglishValue":"69","MetricUnit":"kW","MetricValue":"52","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Power Rating Conditions - No De-Rating Required Up To

10000 ft 3048 m
{"Name":"Power Rating Conditions - No De-Rating Required Up To","SpecificationId":null,"TextValue":null,"EnglishUnit":"ft","EnglishValue":"10000","MetricUnit":"m","MetricValue":"3048","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Net Torque Rise - 1,400 rpm - SAE J1349

308 ft-lb 418 N·m
{"Name":"Net Torque Rise - 1,400 rpm - SAE J1349","SpecificationId":null,"TextValue":null,"EnglishUnit":"ft-lb","EnglishValue":"308","MetricUnit":"N·m","MetricValue":"418","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Ratings at 2,200 rpm - Gross Power ISO 14396

74 HP 55 kW
{"Name":"Ratings at 2,200 rpm - Gross Power ISO 14396","SpecificationId":null,"TextValue":null,"EnglishUnit":"HP","EnglishValue":"74","MetricUnit":"kW","MetricValue":"55","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Net Torque Rise - 1,400 rpm

85%
{"Name":"Net Torque Rise - 1,400 rpm","SpecificationId":null,"TextValue":"85%","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}
Ratings at 2,200 rpm - Gross Power SAE J1995

75 HP 56 kW
{"Name":"Ratings at 2,200 rpm - Gross Power SAE J1995","SpecificationId":null,"TextValue":null,"EnglishUnit":"HP","EnglishValue":"75","MetricUnit":"kW","MetricValue":"56","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Engine Model

C3.6 55 kW (74 hp) Electronic Turbo Intercooled
{"Name":"Engine Model","SpecificationId":null,"TextValue":"C3.6 55 kW (74 hp) Electronic Turbo Intercooled","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Engine","SortOrder":"99"}
Net Peak Power Rating @ 2,200 rpm - ISO 9249

71 HP 53 kW
{"Name":"Net Peak Power Rating @ 2,200 rpm - ISO 9249","SpecificationId":null,"TextValue":null,"EnglishUnit":"HP","EnglishValue":"71","MetricUnit":"kW","MetricValue":"53","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Dimensions - Bore

3.86 in 98 mm
{"Name":"Dimensions - Bore","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"3.86","MetricUnit":"mm","MetricValue":"98","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Net Peak Power Rating @ 2,200 rpm - SAE J1349

70 HP 52 kW
{"Name":"Net Peak Power Rating @ 2,200 rpm - SAE J1349","SpecificationId":null,"TextValue":null,"EnglishUnit":"HP","EnglishValue":"70","MetricUnit":"kW","MetricValue":"52","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}
Dimensions - Stroke

4.72 in 120 mm
{"Name":"Dimensions - Stroke","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"4.72","MetricUnit":"mm","MetricValue":"120","Type":"measurement","SpecificationGroup":"Engine","SortOrder":"99"}

Hydraulic System

Pump Type

Variable-flow, Axial Piston
{"Name":"Pump Type","SpecificationId":null,"TextValue":"Variable-flow, Axial Piston","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Hydraulic System","SortOrder":"91"}
Type

Closed Center
{"Name":"Type","SpecificationId":null,"TextValue":"Closed Center","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
System Pressure - Loader

3336 psi 23000 kPa
{"Name":"System Pressure - Loader","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"3336","MetricUnit":"kPa","MetricValue":"23000","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
System Pressure - Backhoe

3336 psi 23000 kPa
{"Name":"System Pressure - Backhoe","SpecificationId":null,"TextValue":null,"EnglishUnit":"psi","EnglishValue":"3336","MetricUnit":"kPa","MetricValue":"23000","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}
Pump Capacity at 2,200 rpm

34.9 gal/min 132 l/min
{"Name":"Pump Capacity at 2,200 rpm","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal/min","EnglishValue":"34.9","MetricUnit":"l/min","MetricValue":"132","Type":"measurement","SpecificationGroup":"Hydraulic System","SortOrder":"99"}

Service Refill Capacities

Hydraulic System

25.1 gal (US) 95 l
{"Name":"Hydraulic System","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"25.1","MetricUnit":"l","MetricValue":"95","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Rear Axle - Planetaries

0.4 gal (US) 1.7 l
{"Name":"Rear Axle - Planetaries","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"0.4","MetricUnit":"l","MetricValue":"1.7","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Cooling System with Air Conditioning

4.8 gal (US) 18 l
{"Name":"Cooling System with Air Conditioning","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"4.8","MetricUnit":"l","MetricValue":"18","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Rear Axle

4.2 gal (US) 16 l
{"Name":"Rear Axle","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"4.2","MetricUnit":"l","MetricValue":"16","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Hydraulic Tank

11.1 gal (US) 42 l
{"Name":"Hydraulic Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"11.1","MetricUnit":"l","MetricValue":"42","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Fuel Tank

42.3 gal (US) 160 l
{"Name":"Fuel Tank","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"42.3","MetricUnit":"l","MetricValue":"160","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Engine Oil - With Filter

2.4 gal (US) 9 l
{"Name":"Engine Oil - With Filter","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"2.4","MetricUnit":"l","MetricValue":"9","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Transmission - Power Shuttle - AWD

4.8 gal (US) 18 l
{"Name":"Transmission - Power Shuttle - AWD","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"4.8","MetricUnit":"l","MetricValue":"18","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Front Axle (AWD) - Planetaries

0.2 gal (US) 0.7 l
{"Name":"Front Axle (AWD) - Planetaries","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"0.2","MetricUnit":"l","MetricValue":"0.7","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Front Axle (AWD)

2.9 gal (US) 11 l
{"Name":"Front Axle (AWD)","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"2.9","MetricUnit":"l","MetricValue":"11","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}
Transmission - Power Shift - AWD

5 gal (US) 19 l
{"Name":"Transmission - Power Shift - AWD","SpecificationId":null,"TextValue":null,"EnglishUnit":"gal (US)","EnglishValue":"5","MetricUnit":"l","MetricValue":"19","Type":"measurement","SpecificationGroup":"Service Refill Capacities","SortOrder":"99"}

Steering

Turning Circle - (inner wheel not braked) - Outside Front Wheels

26.92 ft 8.205 m
{"Name":"Turning Circle - (inner wheel not braked) - Outside Front Wheels","SpecificationId":null,"TextValue":null,"EnglishUnit":"ft","EnglishValue":"26.92","MetricUnit":"m","MetricValue":"8.205","Type":"measurement","SpecificationGroup":"Steering","SortOrder":"99"}
Stroke

4.2 in 106 mm
{"Name":"Stroke","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"4.2","MetricUnit":"mm","MetricValue":"106","Type":"measurement","SpecificationGroup":"Steering","SortOrder":"99"}
Bore

2.6 in 65 mm
{"Name":"Bore","SpecificationId":null,"TextValue":"Front Wheel Steering","EnglishUnit":"in","EnglishValue":"2.6","MetricUnit":"mm","MetricValue":"65","Type":"measurement","SpecificationGroup":"Steering","SortOrder":"99"}
Type

Front Wheel Steering
{"Name":"Type","SpecificationId":null,"TextValue":"Front Wheel Steering","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Steering","SortOrder":"99"}
Power Steering

Hydrostatic
{"Name":"Power Steering","SpecificationId":null,"TextValue":"Hydrostatic","EnglishUnit":"in","EnglishValue":"1.6","MetricUnit":"mm","MetricValue":"40","Type":"text","SpecificationGroup":"Steering","SortOrder":"99"}
Rod Diameter

1.6 in 40 mm
{"Name":"Rod Diameter","SpecificationId":null,"TextValue":"11°","EnglishUnit":"in","EnglishValue":"1.6","MetricUnit":"mm","MetricValue":"40","Type":"measurement","SpecificationGroup":"Steering","SortOrder":"99"}
Turning Circle - (inner wheel not braked) - Outside Widest Loader Bucket

35.25 ft 10.745 m
{"Name":"Turning Circle - (inner wheel not braked) - Outside Widest Loader Bucket","SpecificationId":null,"TextValue":"One Double-Acting","EnglishUnit":"ft","EnglishValue":"35.25","MetricUnit":"m","MetricValue":"10.745","Type":"measurement","SpecificationGroup":"Steering","SortOrder":"99"}
Axle Oscillation

11°
{"Name":"Axle Oscillation","SpecificationId":null,"TextValue":"11°","EnglishUnit":"gal (US)","EnglishValue":"25.1","MetricUnit":"l","MetricValue":"95","Type":"text","SpecificationGroup":"Steering","SortOrder":"99"}
Cylinder

One Double-Acting
{"Name":"Cylinder","SpecificationId":null,"TextValue":"One Double-Acting","EnglishUnit":"gal (US)","EnglishValue":"0.4","MetricUnit":"l","MetricValue":"1.7","Type":"text","SpecificationGroup":"Steering","SortOrder":"99"}

Sustainability

Recyclability

92%
{"Name":"Recyclability","SpecificationId":null,"TextValue":"92%","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Sustainability","SortOrder":"99"}

Transmission

Note

Travel speeds of backhoe loader at full throttle, when equipped with 500/70-24 rear tires.
{"Name":"Note","SpecificationId":null,"TextValue":"Travel speeds of backhoe loader at full throttle, when equipped with 500/70-24 rear tires.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Transmission","SortOrder":"99"}
Power-Shift Transmission - Optional - Forward - 4th

25 mile/h 40 km/h
{"Name":"Power-Shift Transmission - Optional - Forward - 4th","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"25","MetricUnit":"km/h","MetricValue":"40","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power-Shift Transmission - Optional - Reverse - 3rd

17 mile/h 27 km/h
{"Name":"Power-Shift Transmission - Optional - Reverse - 3rd","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"17","MetricUnit":"km/h","MetricValue":"27","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power-Shift Transmission - Optional - Forward - 2nd

5.8 mile/h 9.4 km/h
{"Name":"Power-Shift Transmission - Optional - Forward - 2nd","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"5.8","MetricUnit":"km/h","MetricValue":"9.4","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power-Shift Transmission - Optional - Forward - 3rd

12 mile/h 20 km/h
{"Name":"Power-Shift Transmission - Optional - Forward - 3rd","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"12","MetricUnit":"km/h","MetricValue":"20","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power-Shift Transmission - Optional - Reverse - 2nd

7.6 mile/h 12 km/h
{"Name":"Power-Shift Transmission - Optional - Reverse - 2nd","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"7.6","MetricUnit":"km/h","MetricValue":"12","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power-Shift Transmission - Optional - Forward -1st

3.7 mile/h 5.9 km/h
{"Name":"Power-Shift Transmission - Optional - Forward -1st","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"3.7","MetricUnit":"km/h","MetricValue":"5.9","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power-Shift Transmission - Optional - Reverse - 1st

3.7 mile/h 5.9 km/h
{"Name":"Power-Shift Transmission - Optional - Reverse - 1st","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"3.7","MetricUnit":"km/h","MetricValue":"5.9","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power Shuttle Transmission - Standard - Forward - 3rd

13 mile/h 21 km/h
{"Name":"Power Shuttle Transmission - Standard - Forward - 3rd","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"13","MetricUnit":"km/h","MetricValue":"21","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power Shuttle Transmission - Standard - Forward - 1st

3.4 mile/h 5.5 km/h
{"Name":"Power Shuttle Transmission - Standard - Forward - 1st","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"3.4","MetricUnit":"km/h","MetricValue":"5.5","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power Shuttle Transmission - Standard - Reverse - 4th

23 mile/h 38 km/h
{"Name":"Power Shuttle Transmission - Standard - Reverse - 4th","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"23","MetricUnit":"km/h","MetricValue":"38","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power Shuttle Transmission - Standard - Forward - 2nd

5.7 mile/h 9.1 km/h
{"Name":"Power Shuttle Transmission - Standard - Forward - 2nd","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"5.7","MetricUnit":"km/h","MetricValue":"9.1","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power Shuttle Transmission - Standard - Forward - 4th

23 mile/h 38 km/h
{"Name":"Power Shuttle Transmission - Standard - Forward - 4th","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"23","MetricUnit":"km/h","MetricValue":"38","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power Shuttle Transmission - Standard - Reverse - 1st

3.4 mile/h 5.5 km/h
{"Name":"Power Shuttle Transmission - Standard - Reverse - 1st","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"3.4","MetricUnit":"km/h","MetricValue":"5.5","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power Shuttle Transmission - Standard - Reverse - 2nd

5.7 mile/h 9.1 km/h
{"Name":"Power Shuttle Transmission - Standard - Reverse - 2nd","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"5.7","MetricUnit":"km/h","MetricValue":"9.1","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}
Power Shuttle Transmission - Standard - Reverse - 3rd

13 mile/h 21 km/h
{"Name":"Power Shuttle Transmission - Standard - Reverse - 3rd","SpecificationId":null,"TextValue":null,"EnglishUnit":"mile/h","EnglishValue":"13","MetricUnit":"km/h","MetricValue":"21","Type":"measurement","SpecificationGroup":"Transmission","SortOrder":"99"}

Weights

Operating Weight - Maximum

24251 lb 11000 kg
{"Name":"Operating Weight - Maximum","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"24251","MetricUnit":"kg","MetricValue":"11000","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"3"}
Cab - ROPS/FOPS

306 lb 139 kg
{"Name":"Cab - ROPS/FOPS","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"306","MetricUnit":"kg","MetricValue":"139","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"75"}
Air Conditioning

99 lb 45 kg
{"Name":"Air Conditioning","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"99","MetricUnit":"kg","MetricValue":"45","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"83"}
Auto-Shift Transmission

269 lb 122 kg
{"Name":"Auto-Shift Transmission","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"269","MetricUnit":"kg","MetricValue":"122","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
MP Bucket (0.96 m3/1.25 yd3) - With Fold-Over Forks

2017 lb 915 kg
{"Name":"MP Bucket (0.96 m3/1.25 yd3) - With Fold-Over Forks","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"2017","MetricUnit":"kg","MetricValue":"915","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
Operating Weight - Maximum - ROPS Capacity

24251 lb 11000 kg
{"Name":"Operating Weight - Maximum - ROPS Capacity","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"24251","MetricUnit":"kg","MetricValue":"11000","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
Operating Weight - Estimated*

16279 lb 7384 kg
{"Name":"Operating Weight - Estimated*","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"16279","MetricUnit":"kg","MetricValue":"7384","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
MP Bucket (0.96 m3/1.25 yd3) - Without Fold-Over Forks

1642 lb 745 kg
{"Name":"MP Bucket (0.96 m3/1.25 yd3) - Without Fold-Over Forks","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"1642","MetricUnit":"kg","MetricValue":"745","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
Ride Control

33 lb 15 kg
{"Name":"Ride Control","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"33","MetricUnit":"kg","MetricValue":"15","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
Note

*Machine configuration: standard stick hoe, OROPS canopy, 4WD standard shift transmission, 0.96 m³ (1.25 yd³) GP (General Purpose) loader bucket, 610 mm (24 in) standard duty hoe bucket, front 340/80-18 and rear 500/70-24 tires, 240 kg (530 lb) counterweight, 80 kg (176 lb) operator, full fuel tank.
{"Name":"Note","SpecificationId":null,"TextValue":"*Machine configuration: standard stick hoe, OROPS canopy, 4WD standard shift transmission, 0.96 m³ (1.25 yd³) GP (General Purpose) loader bucket, 610 mm (24 in) standard duty hoe bucket, front 340/80-18 and rear 500/70-24 tires, 240 kg (530 lb) counterweight, 80 kg (176 lb) operator, full fuel tank.","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Weights","SortOrder":"99"}
Loader QC

540 lb 245 kg
{"Name":"Loader QC","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"540","MetricUnit":"kg","MetricValue":"245","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
Counterweights, base - Maximum

1014 lb 460 kg
{"Name":"Counterweights, base - Maximum","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"1014","MetricUnit":"kg","MetricValue":"460","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
Counterweights, base - Stackable, one

529 lb 240 kg
{"Name":"Counterweights, base - Stackable, one","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"529","MetricUnit":"kg","MetricValue":"240","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
Counterweights, base

256 lb 115 kg
{"Name":"Counterweights, base","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"256","MetricUnit":"kg","MetricValue":"115","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}
All-Wheel Drive

STD
{"Name":"All-Wheel Drive","SpecificationId":null,"TextValue":"STD","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":"Weights","SortOrder":"99"}
Extendible Stick (excludes ft. counterweight)

613 lb 278 kg
{"Name":"Extendible Stick (excludes ft. counterweight)","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"613","MetricUnit":"kg","MetricValue":"278","Type":"measurement","SpecificationGroup":"Weights","SortOrder":"99"}

415
