1550 mm (61 in), IT Coupler, Class III

Cat® Pallet Fork Carriages for are designed to meet a wide variety of material handling needs. Use carriages with different length fork tines for moving bulky or palletized materials on construction and industrial sites, handling bagged fertilizer and seed at landscaping and nursery sites.

(416) 667-5511 Request a Quote

Book a Demo

Explore my deals

Specifications

Height

35.3 in 896 mm
{"Name":"Height","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"35.3","MetricUnit":"mm","MetricValue":"896","Type":"measurement","SpecificationGroup":null,"SortOrder":"1"}
Width

61 in 1550 mm
{"Name":"Width","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"61","MetricUnit":"mm","MetricValue":"1550","Type":"measurement","SpecificationGroup":null,"SortOrder":"2"}
Weight

699.1 lb 317.1 kg
{"Name":"Weight","SpecificationId":null,"TextValue":null,"EnglishUnit":"lb","EnglishValue":"699.1","MetricUnit":"kg","MetricValue":"317.1","Type":"measurement","SpecificationGroup":null,"SortOrder":"4"}
Length

14.2 in 361 mm
{"Name":"Length","SpecificationId":null,"TextValue":null,"EnglishUnit":"in","EnglishValue":"14.2","MetricUnit":"mm","MetricValue":"361","Type":"measurement","SpecificationGroup":null,"SortOrder":"5"}
Tine Spacing

180-1320 mm (7-52 in) centerline to centerline
{"Name":"Tine Spacing","SpecificationId":null,"TextValue":"180-1320 mm (7-52 in) centerline to centerline","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"6"}
Interface Type

IT Coupler
{"Name":"Interface Type","SpecificationId":null,"TextValue":"IT Coupler","EnglishUnit":null,"EnglishValue":null,"MetricUnit":null,"MetricValue":null,"Type":"text","SpecificationGroup":null,"SortOrder":"7"}

Benefits

Application

Used for a variety of material handling needs, such as moving bulky or palletized materials on construction and industrial sites, handling bagged fertilizer and seed at landscaping and nursery sites, and similar jobs.

Heavy Duty Backrest

Heavy-duty load backrest structure is functional, durable and easy to see through. It provides operator protection from shifting loads, while maintaining excellent visibility to the fork tips.

Notched Rail-type Carriage

Notched rail-type carriage design allows fork tines to be easily re-spaced or changed and locked into place.

One carriage for all carrying capacities

The fork carriage is designed to meet the load carrying capacity of the largest machine enabling one size to fit all models.
