2.5 m3 (3.2 yd3), HPL-ISO Coupler, Weld-On Adapters
Flat-floor buckets are performance series, general purpose buckets that incorporate a specially designed long floor and a rear cutting edge to provide optimum results and productivity when performing light grading or back-dragging—while retaining all the premium loading-characteristic of the Performance Series.
2.5 m3 (3.2 yd3), HPL-ISO Coupler, Weld-On Adapters
Flat-floor buckets are performance series, general purpose buckets that incorporate a specially designed long floor and a rear cutting edge to provide optimum results and productivity when performing light grading or back-dragging—while retaining all the premium loading-characteristic of the Performance Series.
Product Brochures
Specifications
-
Width107.8 in 2738 mm
-
Height53.1 in 1350 mm
-
Weight2467 lb 1119 kg
-
Length57.9 in 1470 mm
-
Capacity3.2 yd³ 2.5 m³
-
Base Edge Thickness1.3 in 32 mm
-
Interface TypeHPL-ISO Coupler
Benefits
Application
Ideal for back dragging and grading applications. The fill factor for Performance Series buckets can be up to 115% on top of the specified capacity.
Rugged Design
Additional wear plates on bottom surface of bucket improves bucket life in coarse aggregate applications.
Performance Series Technology
Performance Series Technology - Innovations in bucket design that improve load-ability of buckets, increasing productivity and decreasing fuel costs.
Maximum Machine Usage
Bucket capacity and loading characteristics are matched to machine capabilities to ensure maximum usage and productivity.
